Spacial CRN Cover for Cable Clip

Item Number: AK2CA3

1 PCE 0

PanelSeT CRN, S3D/Thalassa PLA, PLS, PLM cover for cable duct. length 2000mm. Cable duct width is 30 mm. Cover component, cabling accessory. (-5 to 60)°C temp for operation. Set of 8. PVC (polyvinyl chloride) made. Blue RAL 5000. 960 °C fire resistance, VDE 0506, DIN 43659, VDE 0660 standards.

Where To Buy

Datasheet

Download

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	3389110570243	-
8	PAC	53389110570248	-
2288	CAR	13389110570240	-

Specifications

Design

Product or component type	cover
Warranty	18 months

Physical

Range compatibility	PanelSeT S3D PanelSeT CRN PanelSeT PLA PanelSeT PLS PanelSeT PLM
Mounting support	cable duct width= 30 mm
Quantity per set	set of 8
Length	2000 mm
Width	30 mm
Net weight	0.2 kg
Ambient air temperature for operation	-5...60 °C
Standards	VDE 0660 VDE 0506 DIN 43659
Reach free of svhc	Yes
Toxic heavy metal free	Yes
Mercury free	Yes
Rohs exemption information	Yes
Eu rohs directive	Compliant

Material

Material	PVC (polyvinyl chloride)

Others

Life cycle assessment data	No
If one of the deliverables is not relevant please give the reason	Accessory
Legacy weee scope	Out
Package 1 bare product quantity	1
Package 2 bare product quantity	8
Package 3 bare product quantity	1792
Average percentage of recycled plastic content	0 %
	At least in Europe
Warranty duration(in months) bmecat	18
Weee label	No
Accessory / separate part category	cabling accessories
Flame retardance	V-0 conforming to UL 94
Fire resistance	960 °C conforming to IEC 60695-2-1/1
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	3.000 cm
Package 1 width	10.000 cm
Package 1 length	200.000 cm
Package 1 weight	242.000 g
Unit type of package 2	CAR
Number of units in package 2	8
Package 2 height	6.000 cm
Package 2 width	10.000 cm
Package 2 length	202.500 cm
Package 2 weight	1.982 kg
Unit type of package 3	PAL
Number of units in package 3	1792
Package 3 height	101.000 cm
Package 3 width	120.000 cm
Package 3 length	202.500 cm
Package 3 weight	475.000 kg
Sustainable packaging	No
Energy efficiency optimized	False
F-gas free	N/A
Updatability	N/A
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	No
Packaging without single use plastic	No
Take-back	No
Warranty (in months)	18

Show all specifications
