PM3000 series PM3255 power meter 2 digital I, 2 digital O, RS485

Item Number: METSEPM3255

1 PCE 0

Where To Buy

Datasheet

Download

Product Dimensions

Width90 mm

Height95 mm

Depth70 mm

See full specifications

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	3606480481611	-

Specifications

Design

Range	PowerLogic
Product or component type	power meter
Market segment	buildings small building cost management: billing: sub feeder buildings medium building cost management: billing: sub feeder buildings large building cost management: billing: sub feeder buildings multi-site cost management: billing: sub feeder data center cost management: billing: sub feeder healthcare cost management: billing: sub feeder industry cost management: billing: sub feeder buildings small building cost management: cost allocation: sub feeder buildings medium building cost management: cost allocation: sub feeder buildings large building cost management: cost allocation: sub feeder buildings multi-site cost management: cost allocation: sub feeder data center cost management: cost allocation: sub feeder healthcare cost management: cost allocation: sub feeder industry cost management: cost allocation: sub feeder
Device application	multi-tariff power monitoring sub billing
Market segment	small commercial residential
Warranty	18 months

Physical

[in] rated current	5 A 1 A
Communication port protocol	Modbus at 9.6...38.4 kbauds
Mounting mode	clip-on
Mounting support	DIN rail
Standards	BS EN 61557-12 IEC 61557-12 EN 61557-12 BS EN 61326-1 IEC 61326-1 EN 61326-1 BS EN 62052-11 IEC 62052-11 EN 62052-11 BS EN 62053-21 IEC 62053-21 EN 62053-21 BS EN 62053-22 IEC 62053-22 EN 62052-22 BS EN 62053-23 IEC 62053-23 EN 62052-23 BS EN 61010-1 EN 61010-1 IEC 61010-1 UL 61010-1 BS EN 61010-2-30 IEC 61010-2-30 EN 61010-2-30 UL 61010-2-30 ANSI C12.20
Product certifications	CE conforming to IEC 61010-1 (safety) CE conforming to EN 61557-12 (power monitor) CE conforming to EN/IEC 61326-1 (EMC) UKCA conforming to BS EN 61010-1 (safety) UKCA conforming to BS EN 61557-12 (power monitor) UKCA conforming to BS EN 61326-1 (EMC) cULus conforming to EN 61010-1 (safety) cULus conforming to UL 61010-1 (safety) EAC (sub-meter) RCM
Width	90 mm
Depth	70 mm
Height	95 mm
Net weight	0.26 kg
Ip degree of protection	IP40 front panel: conforming to IEC 60529 IP20 body: conforming to IEC 60529
Relative humidity	5...95 % at 50 °C
Ambient air temperature for operation	-25...70 °C
Ambient air temperature for storage	-40...85 °C
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP1112075EN
Reach regulation	Reference contains Substances of Very High Concern above the threshold
China rohs regulation	X
Eu rohs directive	Compliant By Exemption
California proposition 65	WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Others

Legacy weee scope	In
Package 1 bare product quantity	1
Package 2 bare product quantity	16
Package 3 bare product quantity	384
Average percentage of recycled plastic content	0 %
	At least in Europe
Warranty duration(in months) bmecat	18
Weee label	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Product name	PowerLogic PM3000
Device short name	PM3255
Power quality analysis	up to the 15th harmonic
Type of measurement	active and reactive power apparent power current voltage energy power factor frequency total current harmonic distortion THD (I) total voltage harmonic distortion THD (U)
[us] rated supply voltage	100...277 V AC 45...65 Hz 173...480 V AC 45...65 Hz 100...300 V DC
Network frequency	60 Hz 50 Hz
Poles description	3P 3P + N 1P + N
Power consumption in va	5 VA
Display type	backlit LCD
Display resolution	128 x 96 pixels
Sampling rate	32 samples/cycle
Measurement current	0.02...1.2 A 0.05...6 A
Analogue input type	current 0...5 A current 0...1 A
Measurement voltage	50...330 V AC 45...65 Hz direct 50...330 V AC 45...65 Hz phase to neutral 80...570 V AC 45...65 Hz direct 80...570 V AC 45...65 Hz phase to phase 570...999000 V AC 45...65 Hz with external VT
Frequency measurement range	45...65 Hz
Number of inputs	2 digital 0...4 mA 11...40 V DC
Measurement accuracy	current 0.3 % 0.5...6 A current 0.5 % 0.1...1.2 A voltage 0.3 % 50...330 V voltage 0.3 % 80...570 V
Accuracy class	class 0.5S active energy conforming to IEC 62053-22 class 1 active energy conforming to IEC 62053-21 class 2 reactive energy conforming to IEC 62053-23 class C active energy conforming to EN 50470-3
Number of outputs	2 digital (static)
Information displayed	tariff (4)
Communication port support	RS485
Data recording	energy consumption logs 15 alarms power logs time stamping min/max of instantaneous values
Memory capacity	512 KB
Electromagnetic compatibility	electrostatic discharge level 4 conforming to IEC 61000-4-2 susceptibility to electromagnetic fields level 3 conforming to IEC 61000-4-3 electrical fast transient/burst immunity test level 4 conforming to IEC 61000-4-4 surge immunity test level 4 conforming to IEC 61000-4-5 conducted RF disturbances level 3 conforming to IEC 61000-4-6 magnetic field at power frequency - test level: 0.5 mT conforming to IEC 61000-4-8 conducted and radiated emissions class B conforming to EN 55022
Overvoltage category	III
Pollution degree	2
Operating altitude	< 3000 m
Compatibility code	PM3255
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	9.400 cm
Package 1 width	13.900 cm
Package 1 length	14.000 cm
Package 1 weight	422.000 g
Unit type of package 2	S03
Number of units in package 2	16
Package 2 height	30.000 cm
Package 2 width	30.000 cm
Package 2 length	40.000 cm
Package 2 weight	7.036 kg
Unit type of package 3	P12
Number of units in package 3	384
Package 3 height	95.000 cm
Package 3 width	80.000 cm
Package 3 length	120.000 cm
Package 3 weight	177.864 kg
Green premium status for reporting	Green Premium product
Total lifecycle carbon footprint	105 kg CO2 eq.
Carbon footprint of the manufacturing phase [a1 to a3]	11.45845167280039
Carbon footprint of the manufacturing phase [a1 to a3]	11 kg CO2 eq.
Carbon footprint of the distribution phase [a4]	1.060470267718614
Carbon footprint of the distribution phase [a4]	1 kg CO2 eq.
Carbon footprint of the installation phase [a5]	0.008852425292849813
Carbon footprint of the installation phase [a5]	0 kg CO2 eq.
Carbon footprint of the use phase [b2, b3, b4, b6]	92.11646185236033
Carbon footprint of the use phase [b2, b3, b4, b6]	92 kg CO2 eq.
Sustainable packaging	No
Carbon footprint of the end-of-life phase [c1 to c4]	0.8158451539357584
Carbon footprint of the end-of-life phase [c1 to c4]	0.8 kg CO2 eq.
Energy efficiency optimized	False
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Total lifecycle carbon footprint	105.46008137210794
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	No
Packaging without single use plastic	No
Scip number	3255e6c8-2417-4c31-a11c-24ab24365eec
China rohs label	7
End of life manual availability	ENVEOLI111258EN_V1
Take-back	No
Weee label	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Warranty (in months)	18
