Metal Clad Switch 6 Pole, 32A, 415V, Made of Cast Aluminium

Item Number: WMS632

1 PCE 0

Where To Buy

Datasheet

Download

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	9311554684617	-

Specifications

Design

Range of product

Wilco
Series A

Product brand

Clipsal

Physical

Device presentation

basic element with complete housing

Control type

rotary knob

Number of poles

Device mounting

base mounting

Local signalling

without

[ue] rated operational voltage

415 V AC

Rated current

32 A

Marking

ON-OFF

Fixing mode

by screws

Switch function

6-pole

Environmental disclosure

ENVPEP120506EN

Eu rohs directive

Compliant with Exemptions

China rohs regulation

Product out of China RoHS scope

Eu rohs directive

Compliant By Exemption

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Material

Material

cast aluminium

Others

Legacy weee scope

Package 1 bare product quantity

Outside of Europe

Warranty duration(in months) bmecat

Weee label

N/A

Marking location

marking on surface

Unit type of package 1

PCE

Number of units in package 1

Package 1 weight

1.04 kg

Sustainable packaging

China rohs label

End of life manual availability

N/A

Warranty (in months)

Show all specifications
