Metal Clad Reversing Switch 3 Pole, 32A, 415V, Made of Cast Aluminium

Item Number: WMS332R

1 PCE 0

Where To Buy

Datasheet

Download

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	9311554684488	-

Specifications

Design

Range of product	MetalClad Series A
Product brand	Clipsal
Product or component type	switch
Device application	control
Colour tint	yellow

Physical

Device presentation	complete product
Control type	rotary knob
Number of poles	3
Device mounting	base mounting
Ip degree of protection	IP66
Local signalling	without
[ue] rated operational voltage	415 V AC 50 Hz
Rated current	32 A
Marking	ON-OFF
Fixing mode	by screws
Switch function	3-pole
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP120809EN_V1-EN
Eu rohs directive	Compliant By Exemption

Material

Material	cast aluminium

Others

Legacy weee scope	In
Package 1 bare product quantity	1
Package 2 bare product quantity	5
Average percentage of recycled plastic content	0 %
	Outside of Europe
Weee label	N/A
Weee applicability	Finished product
Warranty duration(in months) bmecat	18
Switch application	on/off switching
Marking location	marking on surface
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	10.2 cm
Package 1 width	13.75 cm
Package 1 length	13.95 cm
Package 1 weight	1.04 kg
Unit type of package 2	CAR
Number of units in package 2	5
Package 2 height	23.7 cm
Package 2 width	20.3 cm
Package 2 length	30 cm
Package 2 weight	5.45 kg
Green premium status for reporting	Green Premium product
Total lifecycle carbon footprint	12 kg CO2 eq.
Carbon footprint of the manufacturing phase [a1 to a3]	5.560722091439483
Carbon footprint of the manufacturing phase [a1 to a3]	6 kg CO2 eq.
Carbon footprint of the distribution phase [a4]	0.3118324625823491
Carbon footprint of the distribution phase [a4]	0.3 kg CO2 eq.
Carbon footprint of the installation phase [a5]	0.1908957576239932
Carbon footprint of the installation phase [a5]	0.2 kg CO2 eq.
Carbon footprint of the use phase [b2, b3, b4, b6]	3.4192
Carbon footprint of the use phase [b2, b3, b4, b6]	3 kg CO2 eq.
Sustainable packaging	No
Carbon footprint of the end-of-life phase [c1 to c4]	2.5493896867741186
Carbon footprint of the end-of-life phase [c1 to c4]	3 kg CO2 eq.
Pvc free	No
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Total lifecycle carbon footprint	12.032039998419943
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	Yes
Packaging without single use plastic	No
Pvc free	No
End of life manual availability	N/A
Take-back	No
Warranty (in months)	18
