Harmony Control Relays Modular temperature 3-phase Control Relay 5A, 2 NO, 24..240V AC/DC
Item Number: RM35ATW5MW
Datasheet
Specifications
Design
Range of product
Product or component type
Warranty
Physical
Connections - terminals
[in] rated current
Width
Marking
- CE : EMC 89/336/EEC
- CE : 73/23/EEC
Insulation resistance
- > 500 MOhm at 500 V DC between supply and relay output conforming to IEC 60255-5
- > 500 MOhm at 500 V DC between measurement and relay output conforming to IEC 60664-1
- > 1 MOhm at 500 V DC between supply and measurement conforming to IEC 60255-5
- > 500 MOhm at 500 V DC between supply and relay output conforming to IEC 60664-1
- > 500 MOhm at 500 V DC between measurement and relay output conforming to IEC 60255-5
- > 1 MOhm at 500 V DC between supply and measurement conforming to IEC 60664-1
Connections - terminals
- screw terminals, 1 x 0.5...1 x 4 mm² (AWG 20...AWG 11) solid without cable end
- screw terminals, 2 x 0.5...2 x 2.5 mm² (AWG 20...AWG 14) solid without cable end
- screw terminals, 1 x 0.2...1 x 2.5 mm² (AWG 24...AWG 12) flexible with cable end
- screw terminals, 2 x 0.2...2 x 1.5 mm² (AWG 24...AWG 16) flexible with cable end
Mounting support
Electrical durability
Mechanical durability
Control type
Standards
- NF EN 60255-6
- IEC 60255-6
Product certifications
- GL
- UL
- C-Tick
- CSA
- GOST
Ambient air temperature for storage
Ambient air temperature for operation
Ip degree of protection
- IP20 (terminals) conforming to IEC 60529
- IP30 (casing) conforming to IEC 60529
Mercury free
Rohs exemption information
Environmental disclosure
Eu rohs directive
China rohs regulation
Eu rohs directive
China rohs regulation
California proposition 65
Material
Contacts material
Others
Package 1 bare product quantity
Legacy weee scope
Warranty duration(in months) bmecat
Weee label
Relay type
Product specific application
Relay name
Relay monitored parameters
- phase sequence
- phase failure detection
- under temperature: -1...11°C
- over temperature: 34...46°C
Time delay range
Switching capacity in va
Minimum switching current
Maximum power consumption in va
Utilisation category
- AC-12 conforming to IEC 60947-5-1
- AC-13 conforming to IEC 60947-5-1
- AC-14 conforming to IEC 60947-5-1
- AC-15 conforming to IEC 60947-5-1
- DC-12 conforming to IEC 60947-5-1
- DC-13 conforming to IEC 60947-5-1
- DC-14 conforming to IEC 60947-5-1
Time delay type
Measurement range
- 208...480 V AC
- +/- 1...46 °C
[uc] control circuit voltage
Contacts type and composition
Reset time
Maximum switching voltage
[us] rated supply voltage
[us] rated supply voltage
Supply voltage limits
- 20.4...264 V AC
- 21.6...264 V DC
Maximum power consumption in w
Resistance across terminals
- 600 kOhm at 3-phase
- 1.33 kOhm at temperature
Output contacts
Nominal output current
Run-up delay at power-up
Measurement accuracy
Response time
- <= 3.5 s + Tt (in case of temperature fault)
- 500 ms (in case of 3-phase fault)
- 500 ms (on disappearance of fault)
Temperature probe type
Installed device
Overvoltage category
[ui] rated insulation voltage
Control circuit voltage limits
- - 10 % + 10 % Un DC
- - 15 % + 10 % Un AC
Supply frequency
Operating position
Tightening torque
Housing material
Status led
- 1 LED green for power ON
- 1 LED yellow for correct temperature (high R1)/(low R2)
- 1 LED yellow for phases of relay
Operating rate
Compatibility code
Immunity to microbreaks
Electromagnetic compatibility
- emission standard for industrial environments conforming to IEC 61000-6-4
- emission standard for residential, commercial and light-industrial environments conforming to IEC 61000-6-3
- immunity for industrial environments conforming to NF EN/IEC 61000-6-2
Vibration resistance
- 0.35 mm (f= 5-57.6 Hz) conforming to IEC 60068-2-6/IEC 60255-21-1
- 1 gn (f= 57.6-150 Hz) conforming to IEC 60068-2-6/IEC 60255-21-1
Shock resistance
Pollution degree
Dielectric test voltage
Non-dissipating shock wave
Unit type of package 1
Number of units in package 1
Package 1 height
Package 1 width
Package 1 length
Package 1 weight
Unit type of package 2
Number of units in package 2
Package 2 height
Package 2 width
Package 2 length
Package 2 weight
Sustainable packaging
Packaging made with recycled cardboard
Packaging without single use plastic
Scip number
China rohs label
End of life manual availability
Warranty (in months)
