Harmony XALD XALK Control station plastic, dark grey lid, 1 selector key switch 22mm, 1NO
Item Number: XALD144
Datasheet
Specifications
Design
Range of product
Product or component type
Product destination
Warranty
Physical
Cable entry
- 2 knock-outs for cable entry, clamping capacity: 14-14 mm
- 2 knock-outs for Pg 13 cable gland and ISO M20, clamping capacity: 12-12 mm
Net weight
Mechanical durability
Connections - terminals
- screw clamp terminals, <= 2 x 1.5 mm² with cable end conforming to IEC 60947-1
- screw clamp terminals, >= 1 x 0.22 mm² without cable end conforming to IEC 60947-1
[ie] rated operational current
- 6 A at 120 V, AC-15, A600 conforming to IEC 60947-5-1
- 3 A at 240 V, AC-15, A600 conforming to IEC 60947-5-1
- 1.2 A at 600 V, AC-15, A600 conforming to IEC 60947-5-1
- 0.55 A at 125 V, DC-13, Q600 conforming to IEC 60947-5-1
- 0.27 A at 250 V, DC-13, Q600 conforming to IEC 60947-5-1
- 0.1 A at 600 V, DC-13, Q600 conforming to IEC 60947-5-1
Electrical durability
- 1000000 cycles, AC-15, 2 A at 230 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to IEC 60947-5-1 appendix C
- 1000000 cycles, AC-15, 3 A at 120 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to IEC 60947-5-1 appendix C
- 1000000 cycles, AC-15, 4 A at 24 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to IEC 60947-5-1 appendix C
- 1000000 cycles, DC-13, 0.2 A at 110 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to IEC 60947-5-1 appendix C
- 1000000 cycles, DC-13, 0.5 A at 24 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to IEC 60947-5-1 appendix C
Ambient air temperature for storage
Ambient air temperature for operation
Ip degree of protection
- IP66 conforming to IEC 60529
- IP67
- IP69
- IP69K
Ik degree of protection
Standards
- IEC 60947-5-1
- CSA C22.2 No 14
- UL 508
- JIS C8201-5-1
- IEC 60947-5-5
- IEC 60947-5-4
- IEC 60947-1
- JIS C8201-1
Reach regulation
Eu rohs directive
Mercury free
China rohs regulation
Rohs exemption information
Environmental disclosure
Circularity profile
California proposition 65
Material
Material
Contacts material
Others
Package 1 bare product quantity
Device short name
Control station application
Colour of base of enclosure
Colour of cover
Operator profile
Operators description
Control station composition
Marking location
Contact operation
Resistance to high pressure washer
Operator position information
Key number
Key withdrawal position
Positive opening
Operating travel
Torque value
Tightening torque
Shape of screw head
- cross compatible with Philips no 1 screwdriver
- cross compatible with pozidriv No 1 screwdriver
- slotted compatible with flat Ø 4 mm screwdriver
- slotted compatible with flat Ø 5.5 mm screwdriver
Short-circuit protection
[ith] conventional free air thermal current
[ui] rated insulation voltage
[uimp] rated impulse withstand voltage
Electrical reliability
- λ < 10exp(-6) at 5 V, 1 mA conforming to IEC 60947-5-4
- λ < 10exp(-8) at 17 V, 5 mA conforming to IEC 60947-5-4
Compatibility code
Protective treatment
Overvoltage category
Nema degree of protection
- NEMA 13
- NEMA 4X
Vibration resistance
Shock resistance
- 30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27
- 50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27
Unit type of package 1
Number of units in package 1
Package 1 height
Package 1 width
Package 1 length
Package 1 weight
Unit type of package 2
Number of units in package 2
Package 2 height
Package 2 width
Package 2 length
Package 2 weight
Packaging made with recycled cardboard
Packaging without single use plastic
Green premium status for reporting
Scip number
Sustainable packaging
Weee
Take-back
Take-back
Product contributes to saved and avoided emissions
Removable battery
Carbon footprint (kg.eq.co2 per cr, total life cycle)
Global warming ; total life cycle
Minimum percentage of recycled plastic content
