Easy56 Socket 4 Pin, 10A, 500V

Item Number: EY56SO410

1 PCE 0

Where To Buy

Datasheet

Download

Product Dimensions

Width101 mm

Height101 mm

Depth101 mm

See full specifications

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	9311554782900	-

Specifications

Design

Product or component type	socket-outlet
Market segment	utility industry small commercial

Physical

Mounting mode	surface mounted
[in] rated current	10 A
Pin number	4 pins
[ue] rated operational voltage	500 V
Connections - terminals	screw terminals 1.5-6 mm² rigid or stranded cable
Wire stripping length	16 mm
Net weight	0.471 kg
Height	101 mm
Width	101 mm
Depth	101 mm
Standards	AS/NZS 3123
Ip degree of protection	IP66 conforming to AS 60529
Ambient air temperature for operation	-25...75 °C
Ambient air temperature for storage	-25...75 °C
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP2511024EN
Eu rohs directive	Compliant By Exemption

Material

Material	polycarbonate: cover
Contacts material	pins: brass

Others

Legacy weee scope	In
Package 1 bare product quantity	1
Average percentage of recycled plastic content	0 %
	Outside of Europe
Warranty duration(in months) bmecat	18
Weee label	N/A
Weee applicability	Finished product
Product name	Easy56
Device short name	EY56SO410
Plug, socket category	low voltage
Poles description	3P + E
Network type	AC
Outlet standard deviation	Australian/New Zealand
Plug, socket, control station shape	straight
Shape of pin	tubular
Network frequency	50 Hz
Targeted country	Australia New Zealand
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	11.4 cm
Package 1 width	10.5 cm
Package 1 length	10.8 cm
Package 1 weight	518.0 g
Green premium status for reporting	Green Premium product
Total lifecycle carbon footprint	3 kg CO2 eq.
Carbon footprint of the manufacturing phase [a1 to a3]	3.069660788863109
Carbon footprint of the manufacturing phase [a1 to a3]	3 kg CO2 eq.
Carbon footprint of the distribution phase [a4]	0.07512322041763342
Carbon footprint of the distribution phase [a4]	0.1 kg CO2 eq.
Carbon footprint of the installation phase [a5]	0.003392599535962877
Carbon footprint of the installation phase [a5]	0 kg CO2 eq.
Carbon footprint of the use phase [b2, b3, b4, b6]	0.1404969837587007
Carbon footprint of the use phase [b2, b3, b4, b6]	0.1 kg CO2 eq.
Sustainable packaging	No
Carbon footprint of the end-of-life phase [c1 to c4]	0.10394853828306265
Carbon footprint of the end-of-life phase [c1 to c4]	0.1 kg CO2 eq.
Pvc free	Yes
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Total lifecycle carbon footprint	3.392599535962877
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	Yes
Packaging without single use plastic	No
Pvc free	Yes
End of life manual availability	N/A
Take-back	No
Warranty (in months)	18
