Clipsal - 56 Series Surface Switch 1 Gang, 3 Pole, 500VAC, 25A, Heavy Duty

Clipsal - 56 Series Surface Switch 1 Gang, 3 Pole, 500VAC, 25A, Heavy Duty | Grey

Item Number: 56SWH325-GY

Datasheet

Product Dimensions

Width icon

Width101 mm

Height icon

Height204 mm

Depth icon

Depth172 mm

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range of product

Series 56

Range

Clipsal - 56 Series

Product brand

Clipsal

Product or component type

switch

Device application

control

Colour

cover: grey

Market segment

small commercial|industry|utility

Sustainable offer status

Green Premium product

Physical

Device presentation

basic element with full cover plate

Control type

rotary knob

Number of poles

3

Device mounting

surface

Local signalling

without

[ue] rated operational voltage

500 V AC 50 Hz

Rated current

25 A

Marking

without marking

Fixing mode

by screws

Height

204 mm

Width

101 mm

Depth

172 mm

Net weight

0.88 kg

Switch function

3-pole

Ambient air temperature for operation

-25...75 °C

Ip degree of protection

IP66 conforming to AS 60529

Standards

AS/NZS 3133

Eu rohs directive

Compliant with Exemptions

Rohs exemption information

Yes

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Environmental disclosure

ENVPEP120809EN

Circularity profile

N/A

Material

Material

PC (polycarbonate)

Others

Commercial status history

SESA301466 | Thu Aug 10 18:38:00 EDT 2023 | From Import Local | From 18 to 19

Package 1 bare product quantity

1

Handle colour

red

Suitability for isolation

yes

Poles description

3P

Tightening torque

0.8 N.m

Breaking capacity

25 kA

Targeted country

Australia

Motor m-rating as3133

M110 at 690 V

Rotary handle padlocking

2 padlocks 8-8 mm

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

11.2 cm

Package 1 width

10.2 cm

Package 1 length

20.4 cm

Package 1 weight

0.9 kg
