Clipsal - 56 Series, Surface Socket, IP66, 500V 40A - 4 Round Pins Grey
Item Number: 56SO440-GY
Specifications
Design
Range of product
Series 56
Range
Clipsal - 56 Series
Product brand
Clipsal
Product or component type
socket-outlet
Device application
power supply
Market segment
- utility
- small commercial
- industry
Physical
Device mounting
surface
Mounting mode
external mounting
[in] rated current
40 A
[ue] rated operational voltage
500 V AC 50 Hz conforming to EN 60309-2
Connections - terminals
screw terminals 6-16 mm² rigid or stranded cable
Socket number
1
Outlet standard
industrial
Net weight
0.64 kg
Depth
102 mm
Width
101 mm
Height
107 mm
Ambient air temperature for operation
-25...75 °C
Standards
AS/NZS 3112
China rohs regulation
Product out of China RoHS scope. Substance declaration for your information
Material
Material
polycarbonate: cover
Contacts material
screws: brass
Others
Commercial status history
- SESA301466
- Thu Aug 10 18:38:00 EDT 2023
- From Import Local
- From 18 to 19
Package 1 bare product quantity
1
Outlet standard deviation
Australian/New Zealand
Plug, socket category
low voltage
Poles description
3P + E
Voltage colour
black
Duration
7 h
Tightening torque
0.8 N.m
Socket-outlet type
O
Targeted country
Australia
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
11.2 cm
Package 1 width
10.5 cm
Package 1 length
10.5 cm
Package 1 weight
620.0 g
