Clipsal - 56 Series, Straight Plug, IP66, 500V 32A - 5 Round Pins

Clipsal - 56 Series, Straight Plug, IP66, 500V 32A - 5 Round Pins Electric Orange

Item Number: 56P532-EO

Datasheet

Product Dimensions

Width icon

Width79 mm

Height icon

Height79 mm

Depth icon

Depth168 mm

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range

Clipsal - 56 Series

Range of product

Series 56

Product brand

Clipsal

Product or component type

plug

Device application

power supply

Colour

orange (RAL 2004)

Market segment

utility|small commercial|industry

Sustainable offer status

Green Premium product

Physical

[in] rated current

32 A

[ue] rated operational voltage

500 V AC 50 Hz conforming to EN 60309-2

Outlet standard

industrial

Connections - terminals

screw terminal 2.5-25 mm²

Wire stripping length

20 mm|50 mm

Cable entry

cable gland

Net weight

0.42 kg

Height

79 mm

Width

79 mm

Depth

168 mm

Standards

AS/NZS 3123

Ip degree of protection

IP66 conforming to AS 60529

Ambient air temperature for operation

-25...75 °C

Reach regulation

Reference contains Substances of Very High Concern above the threshold

Eu rohs directive

Compliant with Exemptions

Rohs exemption information

Yes

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Environmental disclosure

ENVPEP121020EN

Circularity profile

N/A

Material

Material

plastic

Material

polycarbonate: housing

Contacts material

pins: brass

Others

Package 1 bare product quantity

1

Poles description

3P + N + E

Voltage colour

black

Plug, socket category

low voltage

Thread type

M40

Plug, socket, control station shape

straight

Pin arrangement

S

Duration

7 h

Targeted country

Australia

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

9.1 cm

Package 1 width

9 cm

Package 1 length

20 cm

Package 1 weight

419 g

Unit type of package 2

BB1

Number of units in package 2

20

Package 2 height

198 cm

Package 2 width

414 cm

Package 2 length

468 cm

Package 2 weight

8.834 kg

Unit type of package 3

CAR

Number of units in package 3

20

Package 3 height

185 cm

Package 3 width

395 cm

Package 3 length

460 cm

Package 3 weight

9.7 kg
Show all specifications
