Specifications
Design
Range
Clipsal - 56 Series
Product brand
Clipsal
Product or component type
locking clip
Surface finish
gloss
Market segment
- utility
- small commercial
- industry
Physical
Range compatibility
56 Series socket
Mounting mode
surface mounted
Fixing center
84 x 84 mm
Quantity per set
set of 10
Net weight
0.048 kg
Type of packing
carton
Ambient air temperature for operation
-25...75 °C
Ip degree of protection
IP66
Eu rohs directive
Compliant with Exemptions
Mercury free
Yes
Rohs exemption information
Yes
China rohs regulation
Product out of China RoHS scope. Substance declaration for your information
Material
Material
plastic
Others
Commercial status history
- SESA301466
- Thu Aug 10 18:38:00 EDT 2023
- From Import Local
- From 18 to 19
Package 1 bare product quantity
1
Accessory / separate part category
locking accessory
Plug, socket category
low voltage
Targeted country
Australia
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
0.3 cm
Package 1 width
1 cm
Package 1 length
3 cm
Package 1 weight
0.048 kg
Documents & downloads
hide showFilter items
-
All
-
Product Brochures
-
CAD Files and Packs
-
Specification Guide
Frequently Asked Questions
What is the difference between 56SB13 and 56CB13 enclosures?
Hide Show
56CB13 replaces 56SB13 and the key differences between the 56CB13 and 56SB13 series are as follows:
Features and Benefits of 56CB13:
- Cover and cover flap design are more rounded to resist dirt becoming trapped in its surrounds, especially on the top edge.
- The latches on the 56SB13 required rotating the knobs 90 degrees to open or lock and were prone to breakage, where the 56CB13 latch in an identical manner to the 56SO cover flaps. This creates more consistency for the operator and the range so opening and closing of cover flaps is simplified. The new latch design also accepts 56SOLOCK locking accessories
- The DIN Rail position and related assembly is now moulded for added safety and to decrease weight.
Features and Benefits of 56CB13:
- 13 Module DIN Rail to suit RCDs, MCBs, RCBOs and accessories.
- Deep cover providing ample wiring room
- Impact resistant cover
- Lockable cover for padlocking up to 7mm diameter hasp
- Simplified dual latching system for front cover
- Less enclosure version (56CB13LE-GY) available to replace damaged covers
