Clipsal - 56 Series Residual Current Circuit Breaker 2 Pole, 20A, 30mA, Less Enclosure | Grey
Item Number: 56RCLE-GY
Specifications
Design
| Range of product | Series 56 |
|---|---|
| Range | Clipsal - 56 Series |
| Product or component type | residual current circuit breaker (RCCB) |
| Product brand | Clipsal |
| Device application | protection |
| Market segment | industry |
Physical
| [in] rated current | 20 A |
|---|---|
| [ue] rated operational voltage | 250 V AC 50 Hz |
| Control type | push-button |
| Protection type | earth-leakage protection |
| Installation direction | vertical |
| Mounting mode | surface mounted |
| Mounting support | DIN rail |
| Height | 101 mm |
| Width | 101 mm |
| Depth | 65 mm |
| Net weight | 0.3 kg |
| Number of gangs | 1 gang |
| Ip degree of protection | IP66 |
| Ambient air temperature for operation | -25...75 °C |
| Electrical insulation class | class II |
| Mercury free | Yes |
| Rohs exemption information | Yes |
| Environmental disclosure | ENVPEP120809EN |
| Eu rohs directive | Compliant By Exemption |
Material
| Material | polycarbonate |
|---|
