Clipsal - 56 Series, RCD Protected Switched Socket Outlet, 250V, 15A, 3 Flat PIN, IP66, Surface Mount

Home ProductsIndustrial56 SeriesRCD Protected Switched Socket Outlet

Clipsal - 56 Series, RCD Protected Switched Socket Outlet, 250V, 15A, 3 Flat PIN, IP66, Surface Mount GY

Item Number: 56C315RC-GY

Datasheet

Product Dimensions

Width icon

Width101 mm

Height icon

Height204 mm

Depth icon

Depth102 mm

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range of product

Series 56

Range

Clipsal - 56 Series

Product brand

Clipsal

Product or component type

socket-outlet with residual current device

Device application

power supply

Market segment

utility|industry|small commercial

Physical

Number of poles

3

Control type

push-button

Number of power socket outlets

1 protective cover

[in] rated current

15 A

[ue] rated operational voltage

250 V AC 50 Hz

Number of gangs

2 gangs

Installation direction

vertical

Device mounting

surface

Connections - terminals

screw terminals cable(s) 1-6 mm²

Depth

102 mm

Width

101 mm

Height

204 mm

Net weight

0.96 kg

Ambient air temperature for operation

-25...75 °C

Ip degree of protection

IP66

Electrical insulation class

class II

Reach regulation

Reference contains Substances of Very High Concern above the threshold

Eu rohs directive

Compliant with Exemptions

Rohs exemption information

Yes

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Material

Material

polycarbonate

Others

Package 1 bare product quantity

1

Network number of phases

1 phase

Targeted country

Australia

Earth-leakage protection class

type A

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

11.6 cm

Package 1 width

10.8 cm

Package 1 length

20.8 cm

Package 1 weight

1.006 kg

Unit type of package 2

CAR

Number of units in package 2

12

Package 2 height

30.5 cm

Package 2 width

29.6 cm

Package 2 length

43.6 cm

Package 2 weight

12.072 kg

Unit type of package 3

PAL

Number of units in package 3

324

Package 3 height

106.5 cm

Package 3 width

116.5 cm

Package 3 length

116.5 cm

Package 3 weight

345040 g
