Clipsal - 56 Series Mounting Back Box 2 Gang, Vertical Socket Mounting | Chemical Resistant White

Item Number: 56EV2/225-RW

Chemical Resistant White 1 PCE 0
Grey 1 PCE 0

Where To Buy

Datasheet

Download

Product Dimensions

Width145 mm

Height110 mm

Depth110 mm

See full specifications

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	9311554668143	GY
12	CAR	19311554668140	GY
1	PCE	9311554668167	RW
12	CAR	19311554668164	RW

Specifications

Design

Range of product	Series 56
Range	Clipsal - 56 Series
Product brand	Clipsal
Colour	white (RAL 9003)

Physical

Number of gangs	2 gangs
Device mounting	surface
Mounting mode	wall-mounted
Length	104 mm
Width	145 mm
Depth	110 mm
Height	110 mm
Net weight	0.707 kg
Ip degree of protection	IP66 conforming to AS 60529
Standards	AS 3100
Ambient air temperature for operation	-25...75 °C
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP2511029_V1-EN
Reach regulation	Reference contains Substances of Very High Concern above the threshold
China rohs regulation	Product out of China RoHS scope
Eu rohs directive	Compliant By Exemption

Material

Material	PVC (polyvinyl chloride): housing

Others

Legacy weee scope	In
Package 1 bare product quantity	1
Average percentage of recycled plastic content	0 %
	Outside of Europe
Warranty duration(in months) bmecat	18
Weee label	N/A
Weee applicability	Component
Weee exclusion rationale	Component not in scope – non independent function
Cable entry number	2
Compatibility code	56 Series covers
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	12.0 cm
Package 1 width	11.0 cm
Package 1 length	21.0 cm
Package 1 weight	672.5 g
Unit type of package 2	CAR
Number of units in package 2	12
Package 2 height	25.4 cm
Package 2 width	34.8 cm
Package 2 length	44.5 cm
Package 2 weight	8.49 kg
Total lifecycle carbon footprint	5 kg CO2 eq.
Carbon footprint of the manufacturing phase [a1 to a3]	3.603842710184344
Carbon footprint of the manufacturing phase [a1 to a3]	4 kg CO2 eq.
Carbon footprint of the distribution phase [a4]	0.09664881651279943
Carbon footprint of the distribution phase [a4]	0.1 kg CO2 eq.
Carbon footprint of the installation phase [a5]	0.13781741031066522
Carbon footprint of the installation phase [a5]	0.1 kg CO2 eq.
Carbon footprint of the use phase [b2, b3, b4, b6]	0.4007331367058578
Carbon footprint of the use phase [b2, b3, b4, b6]	0.4 kg CO2 eq.
Sustainable packaging	No
Carbon footprint of the end-of-life phase [c1 to c4]	0.4319420114582573
Carbon footprint of the end-of-life phase [c1 to c4]	0.4 kg CO2 eq.
Pvc free	Yes
Halogen-free status	Product contains halogen above thresholds
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Total lifecycle carbon footprint	4.6709840851719235
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	Yes
Packaging without single use plastic	No
Halogen-free status	Product contains halogen above thresholds
Pvc free	Yes
End of life manual availability	ENVEOLI2511029EN
Take-back	No
Warranty (in months)	18
