Clipsal - 56 Series DOL Motor Starter 4kW, 415V, 2 push-button, LRD10 | Grey

Item Number: 56DOL9/6-GY

Grey 1 PCE 0
Chemical Resistant Orange 1 PCE 0

Where To Buy

Datasheet

Download

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	9311554651398	GY
8	CAR	19311554651395	GY
1	PCE	9311554658915	RO
8	CAR	19311554658912	RO

Specifications

Design

Range of product	Series 56
Product or component type	switch
Colour	cover: grey
Product destination	2 push-button
Market segment	utility industry small commercial

Physical

Control type	push-button
[ie] rated operational current	9 A
Connections - terminals	screw terminal solid screw terminal stranded
Height	204 mm
Width	101 mm
Net weight	1.42 kg
Ip degree of protection	IP66 conforming to AS 60529
Ambient air temperature for operation	-25...75 °C
Standards	AS/NZS 3133 AS/NZS 3100
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP2511024EN
Reach regulation	Free of Substances of Very High Concern above the threshold
China rohs regulation	Product out of China RoHS scope
Eu rohs directive	Compliant By Exemption

Others

Legacy weee scope	In
Package 1 bare product quantity	1
Average percentage of recycled plastic content	0 %
	Outside of Europe
Warranty duration(in months) bmecat	18
Weee label	N/A
Weee applicability	Finished product
Motor starter type	direct on line
[us] rated supply voltage	240 V AC 50 Hz
Network type	AC
Rated operational power in w	4 kW at 240 V (AC-3)
Overload current	4...6 A
Tightening torque	0.8 N.m
Network number of phases	3 phases
Targeted country	Australia
Suitability for isolation	no
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	10.3 cm
Package 1 width	16.2 cm
Package 1 length	25.4 cm
Package 1 weight	1418.0 g
Unit type of package 2	CAR
Number of units in package 2	8
Package 2 height	25.4 cm
Package 2 width	34.8 cm
Package 2 length	44.5 cm
Package 2 weight	11.344 kg
Total lifecycle carbon footprint	33 kg CO2 eq.
Carbon footprint of the manufacturing phase [a1 to a3]	14.050380267067439
Carbon footprint of the manufacturing phase [a1 to a3]	14 kg CO2 eq.
Carbon footprint of the distribution phase [a4]	0.3278275251315532
Carbon footprint of the distribution phase [a4]	0.3 kg CO2 eq.
Carbon footprint of the installation phase [a5]	0.19747398367139488
Carbon footprint of the installation phase [a5]	0.2 kg CO2 eq.
Carbon footprint of the use phase [b2, b3, b4, b6]	16.93097502582249
Carbon footprint of the use phase [b2, b3, b4, b6]	17 kg CO2 eq.
Sustainable packaging	No
Carbon footprint of the end-of-life phase [c1 to c4]	1.3610404451489175
Carbon footprint of the end-of-life phase [c1 to c4]	1 kg CO2 eq.
Pvc free	Yes
Halogen-free status	Product contains halogen above thresholds
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Total lifecycle carbon footprint	32.86769724684179
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	Yes
Packaging without single use plastic	No
China rohs label	2
Halogen-free status	Product contains halogen above thresholds
Pvc free	Yes
End of life manual availability	N/A
Take-back	No
Warranty (in months)	18
