Clipsal - 56 Series Appliance Inlet 4 Round PIN, 32A, 500V, IP66 | Electric Orange

Item Number: 56AI432-EO

Electric Orange 1 PCE 0
Grey 1 PCE 0

Where To Buy

Datasheet

Download

Product Dimensions

Width101 mm

Height204 mm

Depth165 mm

See full specifications

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	9311554069452	EO
10	CAR	29311554069456	EO
1	PCE	9311554235598	GY
10	CAR	29311554235592	GY

Specifications

Design

Range	Clipsal - 56 Series
Range of product	Series 56
Product brand	Clipsal
Product or component type	appliance inlet
Device application	power supply
Colour	electric orange (RAL 2004)
Market segment	utility small commercial industry

Physical

[in] rated current	32 A
[ue] rated operational voltage	500 V 50/60 Hz conforming to EN 60309-2
Mounting mode	surface mounted
Outlet standard	industrial
Connections - terminals	screw terminal 6-16 mm² rigid or stranded cable
Net weight	1.1 kg
Height	204 mm
Width	101 mm
Depth	165 mm
Standards	AS/NZS 60320.1
Ip degree of protection	IP66 conforming to AS 60529
Ambient air temperature for operation	-25...75 °C
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP1508011_V2
Eu rohs directive	Compliant By Exemption

Material

Material	plastic
Material	polycarbonate: cover
Contacts material	screws: brass

Others

Legacy weee scope	In
	Outside of Europe
Warranty duration(in months) bmecat	18
Average percentage of recycled plastic content	0 %
Package 1 bare product quantity	1
Weee label	N/A
Weee applicability	Finished product
Poles description	3P + E
Voltage colour	black
Plug, socket category	low voltage
Outlet standard deviation	Australian/New Zealand
Tightening torque	0.8 N.m
Plug, socket, control station shape	straight
Pin arrangement	N
Duration	7 h
Targeted country	Australia
Main colour tint	electric orange
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	20.4 cm
Package 1 width	10.1 cm
Package 1 length	16.5 cm
Package 1 weight	1.1 kg
Green premium status for reporting	Green Premium product
Total lifecycle carbon footprint	0 kg CO2 eq.
Carbon footprint of the manufacturing phase [a1 to a3]	0.0052705323978539
Carbon footprint of the manufacturing phase [a1 to a3]	0 kg CO2 eq.
Carbon footprint of the distribution phase [a4]	0.0001289847296739579
Carbon footprint of the distribution phase [a4]	0 kg CO2 eq.
Carbon footprint of the installation phase [a5]	0.00000582501031778786
Carbon footprint of the installation phase [a5]	0 kg CO2 eq.
Carbon footprint of the use phase [b2, b3, b4, b6]	0.00002133425000000001
Carbon footprint of the use phase [b2, b3, b4, b6]	0 kg CO2 eq.
Sustainable packaging	No
Carbon footprint of the end-of-life phase [c1 to c4]	0.00017847709451093688
Carbon footprint of the end-of-life phase [c1 to c4]	0 kg CO2 eq.
Pvc free	Yes
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Total lifecycle carbon footprint	0.0056441267024349975
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	Yes
Packaging without single use plastic	No
Pvc free	Yes
End of life manual availability	N/A
Take-back	No
Warranty (in months)	18
