Clipsal - 56 Series Adaptable Enclosure 2 Gang, 107x101x75mm, Less Enclosure | Grey

Item Number: 56/32LE-GY

Grey 1 PCE 0
Chemical Resistant Orange 1 PCE 0
Chemical Resistant White 1 PCE 0

Where To Buy

Datasheet

Download

Product Dimensions

Width101 mm

Height107 mm

Depth39 mm

See full specifications

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	9311554004521	GY
45	CAR	19311554004528	GY
1	PCE	9311554335830	RO
45	CAR	19311554335837	RO
1	PCE	9311554721268	RW

Specifications

Design

Range of product	Series 56
Range	Clipsal - 56 Series
Product brand	Clipsal
Colour	grey (RAL 7035)
Product destination	diameter: 20-20 mm tube
Surface finish	bare
Market segment	industry utility small commercial

Physical

Outlet standard	industrial
Number of gangs	2 gangs
Device mounting	surface
Fixing mode	by screws
Length	107 mm
Width	101 mm
Depth	39 mm
Height	107 mm
Net weight	0.176 kg
Ip degree of protection	IP66
Ambient air temperature for operation	-25...75 °C
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP2511029_V1-EN
Reach regulation	Reference contains Substances of Very High Concern above the threshold
China rohs regulation	Product out of China RoHS scope
Eu rohs directive	Compliant By Exemption

Material

Material	polycarbonate: cover

Others

Legacy weee scope	In
Package 1 bare product quantity	1
Average percentage of recycled plastic content	0 %
	Outside of Europe
Warranty duration(in months) bmecat	18
Weee label	N/A
Weee applicability	Component
Weee exclusion rationale	Component not in scope – non independent function
Plug, socket category	low voltage
Cover type	without screening transparent
Lock type	possibility to seal it
Enclosure type	weatherproof enclosure
Shape	rectangular
Location of connection	rear
Tracks	no track
Tightening torque	0.8 N.m
Targeted country	Australia
Compatibility code	30 Mech
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	7 cm
Package 1 width	10.2 cm
Package 1 length	10 cm
Package 1 weight	180 g
Unit type of package 2	CAR
Number of units in package 2	45
Package 2 height	30.5 cm
Package 2 width	29.6 cm
Package 2 length	43.6 cm
Package 2 weight	8100 g
Unit type of package 3	PAL
Number of units in package 3	1215
Package 3 height	106.5 cm
Package 3 width	116.5 cm
Package 3 length	116.5 cm
Package 3 weight	247840 g
Total lifecycle carbon footprint	2 kg CO2 eq.
Carbon footprint of the manufacturing phase [a1 to a3]	0.9645973053281516
Carbon footprint of the manufacturing phase [a1 to a3]	1 kg CO2 eq.
Carbon footprint of the distribution phase [a4]	0.02586882821160431
Carbon footprint of the distribution phase [a4]	0 kg CO2 eq.
Carbon footprint of the installation phase [a5]	0.03688793138426727
Carbon footprint of the installation phase [a5]	0 kg CO2 eq.
Carbon footprint of the use phase [b2, b3, b4, b6]	0.4007331367058578
Carbon footprint of the use phase [b2, b3, b4, b6]	0.4 kg CO2 eq.
Sustainable packaging	No
Carbon footprint of the end-of-life phase [c1 to c4]	0.11561273169142945
Carbon footprint of the end-of-life phase [c1 to c4]	0.1 kg CO2 eq.
Pvc free	Yes
Halogen-free status	Product contains halogen above thresholds
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Total lifecycle carbon footprint	1.5436999333213104
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	Yes
Packaging without single use plastic	No
Halogen-free status	Product contains halogen above thresholds
Pvc free	Yes
End of life manual availability	ENVEOLI2511029EN
Take-back	No
Warranty (in months)	18
