Clipsal - General Accessories Mounting Clip Moulded Front, 1.5mm

Home ProductsElectrical AccessoriesClipsal - General AccessoriesMounting Clip

Clipsal - General Accessories Mounting Clip Moulded Front, 1.5mm | Red

Item Number: F30Z1.5-RD

Where To Buy

Datasheet

PDF datasheet

Download

Barcode

Qty UoM EAN Colour
-
-
-
See all

Specifications

Design

Range of product

  • Standard
  • Sundry Series 30

Product brand

Clipsal

Physical

Mounting position

horizontal and vertical

Depth

9 mm

Length

28 mm

Width

28 mm

Mercury free

Yes

Rohs exemption information

Yes

Eu rohs directive

Pro-active compliance (Product out of EU RoHS legal scope)

Reach regulation

Reference contains Substances of Very High Concern above the threshold

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Material

Material

PVC (polyvinyl chloride)

Others

Legacy weee scope

Out

Package 1 bare product quantity

1

Average percentage of recycled plastic content

0 %

Outside of Europe

Weee label

N/A

Weee applicability

Component

Weee exclusion rationale

Component not in scope – non independent function

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

1.0 cm

Package 1 width

2.8 cm

Package 1 length

2.8 cm

Package 1 weight

1.9 g

Sustainable packaging

Yes

Pvc free

Yes

Halogen-free status

Product contains halogen above thresholds

Take-back

No

Product contributes to saved and avoided emissions

No

Removable battery

N/A

Average percentage of recycled metal content

0 %

Packaging made with recycled cardboard

Yes

Packaging without single use plastic

Yes

Halogen-free status

Product contains halogen above thresholds

Pvc free

Yes

Take-back

No

Warranty (in months)

18
Show all specifications
