Schneider Charge Load-shedder 1P, maximum current allowed to charging station manually set from 32A to 100A

Item Number: EVA2HPC1

1 PCE 0

Where To Buy

Datasheet

Download

Product Dimensions

Width93 mm

Height70 mm

Depth69 mm

See full specifications

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	3606486114162	-

Specifications

Design

Range	Schneider Charge
Product or component type	load-shedder

Physical

Range compatibility	EVlink EVlink Home Schneider Charge Pro
Mounting support	35 mm DIN rail
Power consumption in w	4 W
Local signalling	1 green LED, function: control process 1 red LED, function: fault indication 1 green LED, function: embedded communication status
Standards	EN 61010-1:2010 EN 61326-1:2013
Quantity per set	set of 1
Height	70 mm
Width	93 mm
Depth	69 mm
Net weight	196 g
Ambient air temperature for operation	-30...50 °C
Ambient air temperature for storage	-40...85 °C
Relative humidity	5...95 %
Reach free of svhc	Yes
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP2208006EN
Reach regulation	Free of Substances of Very High Concern above the threshold
China rohs regulation	Product out of China RoHS scope
Eu rohs directive	Compliant By Exemption

Material

Material	plastic

Others

Legacy weee scope	In
China energy label	N/A
China carbon footprint certification	Not certified
Average percentage of responsible steel certified metals	0 %
Average percentage of coppermark certified metals	0 %
Average percentage of asi certified metals	0 %
If one of the deliverables is not relevant please give the reason	Accessories
Life cycle assessment data	No
Package 1 bare product quantity	1
Package 2 bare product quantity	20
Package 3 bare product quantity	80
Average percentage of recycled plastic content	0 %
	At least in Europe
Weee label	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Network number of phases	single phase
Condition of use	indoor
Settings operating mode	manual
Power supply output current	32 A 40 A 50 A 63 A 80 A 100 A
[us] rated supply voltage	220...230 V AC 50/60 Hz +/- 10 %
Connectivity to devices	PLC
Operating altitude	0...2000 m
Overvoltage category	III
Pollution degree	2
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	9.000 cm
Package 1 width	10.000 cm
Package 1 length	17.500 cm
Package 1 weight	533.000 g
Unit type of package 2	S04
Number of units in package 2	20
Package 2 height	30.000 cm
Package 2 width	40.000 cm
Package 2 length	60.000 cm
Package 2 weight	12.170 kg
Unit type of package 3	P12
Number of units in package 3	80
Package 3 height	45.000 cm
Package 3 width	80.000 cm
Package 3 length	120.000 cm
Package 3 weight	56.640 kg
Green premium status for reporting	Green Premium product
Sustainable packaging	No
Pvc free	N/A
Halogen-free status	N/A
Silicone-free	N/A
F-gas free	N/A
Updatability	N/A
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	No
China green design product	No
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	No
Packaging without single use plastic	No
Scip number	35f25d1c-ed42-419a-bab0-354f2d8eb602
End of life manual availability	ENVEOLI2208006_V1
Removable battery	No
Take-back	No
Weee label	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
