EVlink Pro DC 60kW - 2xCCS2 - with cable management

Home ProductsElectric Vehicle ChargersEVlink Pro DC (up to 60 kW)Fast charging station

EVlink Pro DC (up to 60 kW) Fast charging station 60kW wallbox, CCS2 + CCS2 connectors, 5m cable with cable management system

Item Number: EVD1S60TBB-AN

1 PCE 0

Where To Buy

Datasheet

Download

Product Dimensions

Width1303 mm

Height1204 mm

Depth339 mm

See full specifications

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	3606487234142	-

Specifications

Design

Range	EVlink
Product or component type	fast charging station
Device application	Electrical Vehicle charger
Colour	front face: signal white (RAL 9003) body: black (Pantone black C)

Physical

Type of installation	indoor/outdoor
Range compatibility	EVlink EVlink Field Services EVlink EVlink Load Management System
Connector type	SAE CCS Combo 2
Provided equipment	1 energy meter per output
Protection type	short-circuit protection on output overload protection ground fault protection residual current breaker with overcurrent protection (RCBO) temperature rise protection
Type of setting	without
Ambient air temperature for operation	-30...55 °C (with derating above 50 °C)
Height	1204 mm
Width	1303 mm
Depth	339 mm
Net weight	131 kg (without power module) 161 kg (with power module)
Communication port protocol	OCPP 1.6 Modbus TCP Ethernet TCP/IP
Communication network type	4G WLAN Ethernet TCP/IP Wi-Fi
Ip degree of protection	IP55
Ik degree of protection	IK10 screen: IK08
Ambient air temperature for storage	-40...70 °C
Relative humidity	5...95 %, without condensation
Standards	IEC 61851-1:ed. 3 IEC 61851-23:ed. 1 IEC 62196-1 IEC 62196-3 EN/IEC 61000-6-2:2005 EN/IEC 61000-6-4:class A ISO 15118-2 DIN 70121 VDV 261
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP2403020EN
Reach regulation	Reference contains Substances of Very High Concern above the threshold
China rohs regulation	Product out of China RoHS scope
Eu rohs directive	Compliant By Exemption

Material

Material	enclosure: stainless steel 304 aluminium

Others

Average percentage of asi certified metals	0 %
Average percentage of coppermark certified metals	0 %
Legacy weee scope	In
	Outside of Europe
China energy label	N/A
China carbon footprint certification	Not certified
Average percentage of responsible steel certified metals	0 %
Package 1 bare product quantity	1
Average percentage of recycled plastic content	0 %
Weee label	N/A
Product name	EVlink Pro DC
Poles description	3P + N + E
Mounting location	wall mounting floor stand with pedestal (to be ordered separately)
Earthing system	TN-S TN-C-S TT compatible IT with additional isolation transformer on the power supply
[us] rated supply voltage	380...415 V AC at 50 Hz, 3 phases + neutral
Input current	97...107 A
Nominal output power	SAE CCS Combo 2: 60 kW at 1.5-200 A150...1000 V DC
Output type	side: 2 charging cable of 3.6 m
Number of outputs	2
Wiring assembly	With
Access control system	RFID authentication card RFID conforming to ISO/IEC 14443 A and B RFID authentication card NFC free access QR code/application
Display type	LCD touch screen : 7 inch
User language	Danish Dutch English French German Norwegian Spanish
Control button type	charge interruption button
Efficiency	95 %
Power factor	0.99
Services	commercial service plan commissioning service warranty extension up to 5 years repair service
Ethernet service	web browser
Local display	without
Electromagnetic compatibility	immunity for industrial environments: emission standard for industrial environments:
Operating altitude	0...2000 m
Atmospheric-corrosivity category	C3
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	77 cm
Package 1 width	125 cm
Package 1 length	110 cm
Package 1 weight	221 kg
Green premium status for reporting	Green Premium product
Total lifecycle carbon footprint	0 kg CO2 eq.
Carbon footprint of the manufacturing phase [a1 to a3]	0.002114154239735616
Carbon footprint of the manufacturing phase [a1 to a3]	0 kg CO2 eq.
Carbon footprint of the distribution phase [a4]	0.00004211571968197355
Carbon footprint of the distribution phase [a4]	0 kg CO2 eq.
Carbon footprint of the installation phase [a5]	0.00002915892927673
Carbon footprint of the installation phase [a5]	0 kg CO2 eq.
Carbon footprint of the use phase [b2, b3, b4, b6]	0.013093998821207
Carbon footprint of the use phase [b2, b3, b4, b6]	0 kg CO2 eq.
Sustainable packaging	No
Carbon footprint of the end-of-life phase [c1 to c4]	0.00023419511783200815
Carbon footprint of the end-of-life phase [c1 to c4]	0 kg CO2 eq.
Pvc free	N/A
Halogen-free status	N/A
Silicone-free	N/A
F-gas free	N/A
Updatability	N/A
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	No
Total lifecycle carbon footprint	0
China green design product	No
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	No
Packaging without single use plastic	No
Scip number	5ac9138c-a36d-4dcb-9d64-4a599808ae5a
End of life manual availability	ENVEOLI2403020_V1
Removable battery	No
Take-back	No
