EVlink Pro AC Pedestal for 1 charging station

EVlink Pro AC Pedestal for 1 charging station

Item Number: EVA1PBS1

This EVlink Pro AC mounting accessory is a pedestal mounting pole, installed on the floor. It allows to support 1 EVlink Pro AC charging station. The color is dark grey (RAL 7016). The pedestal material is Alu 5754 with zinc phosphate pre-treatment. The dimensions are (H) 1300mm x (W) 285mm x (D) 229mm. Its product weight is 5kg.

Datasheet

Product Dimensions

Width icon

Width285 mm

Height icon

Height1300 mm

Depth icon

Depth229 mm

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range

EVlink

Product or component type

pedestal

Product compatibility

1 x charging station

Device application

Electrical Vehicle charger

Surface treatment

zinc phosphate

Sustainable offer status

Green Premium product

Physical

Type of installation

indoor/outdoor

Mounting mode

floor-standing

Height

1300 mm

Width

285 mm

Depth

229 mm

Net weight

5 kg

Range compatibility

EVlink EVlink Pro AC

Reach regulation

Free of Substances of Very High Concern above the threshold

Reach free of svhc

Yes

Eu rohs directive

Compliant

Mercury free

Yes

Rohs exemption information

Yes

China rohs regulation

 Pro-active China RoHS declaration (out of China RoHS legal scope)

Environmental disclosure

ENVPEP2202024

Circularity profile

ENVEOLI2202024

Material

Material

aluminium 5754

Others

Life cycle assessment data

No

If one of the deliverables is not relevant please give the reason

spare parts, accessories or module, no need in separate

Package 1 bare product quantity

1

Accessory / separate part category

mounting accessory

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

29 cm

Package 1 width

32 cm

Package 1 length

135 cm

Package 1 weight

10.3 kg

Unit type of package 2

PAL

Number of units in package 2

9

Package 2 height

100 cm

Package 2 width

120 cm

Package 2 length

160 cm

Package 2 weight

116 kg

Product contributes to saved and avoided emissions

No
Show all specifications
