EVlink Pro AC Kit enclosure Metal, for 1 wall-mounted charging station, steel

EVlink Pro AC Kit enclosure Metal, for 1 wall-mounted charging station, steel

Item Number: EVA1RWKS1

Datasheet

Product Dimensions

Width icon

Width390 mm

Height icon

Height783 mm

Depth icon

Depth230 mm

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range

EVlink

Product or component type

enclosure

Surface treatment

electro-galvanized

Product compatibility

wall-mounted charging station

Colour

front: white (RAL 9003)|rear: white (RAL 9003)|side: light grey (RAL 9022)

Physical

Range compatibility

EVlink EVlink Pro AC Metal EVB3 charging station

Height

783 mm

Width

390 mm

Depth

230 mm

Net weight

26 kg

Reach regulation

Reference contains Substances of Very High Concern above the threshold

Eu rohs directive

Compliant

Mercury free

Yes

Rohs exemption information

Yes

China rohs regulation

 Pro-active China RoHS declaration (out of China RoHS legal scope)

Environmental disclosure

ENVPEP2202024

Circularity profile

ENVEOLI2202024

Others

Package 1 bare product quantity

1

Accessory / separate part category

enclosure accessory

Enclosure type

kit enclosure

Number of devices

1 charging station

Type of front cover

customizable

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

56.000 cm

Package 1 width

56.000 cm

Package 1 length

90.000 cm

Package 1 weight

36.000 kg

Scip number

1546a912-8240-4bbd-8f51-e9dcb5c45c83

Product contributes to saved and avoided emissions

No

Carbon footprint (kg.eq.co2 per cr, total life cycle)

1.517637972422011
Show all specifications
