EVlink Pro AC Charging station 7.4kW, 32A, 1P+N, T2S socket-outlet, RDC-DD 6mA

EVlink Pro AC Charging station 7.4kW, 32A, 1P+N, T2S socket-outlet, RDC-DD 6mA

Item Number: EVB3S07N41

Datasheet

Product Dimensions

Width icon

Width317 mm

Height icon

Height529 mm

Depth icon

Depth153 mm

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range

EVlink

Product or component type

charging station

Colour

  • front face: white (RAL 9003)
  • housing: dark grey (RAL 7016)
  • back part: black (RAL 9005)

Physical

Communication network type

  • Ethernet
  • bluetooth
  • 3G/4Gmodem optional
  • Modbus TCP

Connector type

2 RJ45 for Ethernet LAN connection

Communication port protocol

OCPP 1.6

Function available

  • charge detail records
  • load management
  • diagnosis capabilities
  • software updates

Range compatibility

  • EVlink EcoStruxure EV Charging Expert
  • EVlink EVlink Pro AC Metal
  • EcoStruxure EcoStruxure EV Advisor

Type of installation

  • indoor
  • outdoor

Provided equipment

1 residual direct current detection device (RDC-DD) integrated

Mounting mode

  • wall-mounted
  • wall-mounted (kit enclosure)
  • floor-standing (pedestal)
  • floor-standing (kit enclosure)

Mounting support

  • pedestal, to be ordered separately
  • kit enclosure, to be ordered separately

Cable entry

  • bottom entry
  • top entry
  • rear entry

Socket number

1

Control type

can be controlled by remote

Local signalling

  • 1 green LED light strip, function: available
  • 1 blue LED light strip, function: charging
  • 1 red LED light strip, function: fault indication

Standards

  • EN/IEC 61851-1:ed. 3
  • EN/IEC 62196-1:ed. 2
  • EN/IEC 62196-2:ed. 1
  • EN 61000-6-2:2019
  • EN 61000-6-3:2007
  • EN 61000-6-3:2011/A1
  • IEC 60884-1
  • NF C 61314
  • ISO 15118

Product certifications

  • EV Ready
  • CE

Height

529 mm

Width

317 mm

Depth

153 mm

Net weight

7.2 kg

Ip degree of protection

IP55

Ambient air temperature for operation

-30...45 °C

Ambient air temperature for storage

-40...80 °C

Reach regulation

Reference contains Substances of Very High Concern above the threshold

Eu rohs directive

Compliant with Exemptions

Rohs exemption information

Yes

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Environmental disclosure

ENVPEP2202024

Circularity profile

ENVEOLI2202024

Others

Commercial status history

  • SESA65410
  • Thu Aug 08 21:16:00 EDT 2024
  • From Unitary Local
  • From 04 to 08

Package 1 bare product quantity

1

Package 2 bare product quantity

4

Product name

EVlink Pro AC

Device short name

EVB3

Communication service

JSON smart charging for OCPP 1.6

Operating mode

  • clustered architecture
  • standalone

Protection device type

residual direct current detection device (RDC-DD) - 6 mA

Poles description

1P + N for power circuit

[us] rated supply voltage

220...240 V AC 50/60 Hz

Nominal output power

7.4 kW 32 A 222...240 V

Output type

front side T2 with shutter socket-outlet / silver plated contacts

Access control system

  • badge RFID conforming to ISO/IEC 14443 A and B
  • badge RFID conforming to ISO/IEC 15693
  • badge NFC
  • free access

Technology type

  • MIFARE Classic
  • MIFARE Ultralight
  • MIFARE Plus

Rfid frequency

13.56 MHz

Nfc tag type

  • type 1
  • type 2
  • type 4
  • type 5

Earthing system

  • TT
  • TN-S
  • TN-C-S
  • IT (single phase network only allowed, 400V 3 phases network forbidden)

Number of inputs

3

Input type

  • binary for power limitation closing contact
  • binary for delayed charging closing contact
  • binary for vehicle detection closing contact

Operating altitude

2000 m without derating

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

28.500 cm

Package 1 width

35.500 cm

Package 1 length

57.500 cm

Package 1 weight

8.200 kg

Unit type of package 2

P06

Number of units in package 2

4

Package 2 height

72.000 cm

Package 2 width

60.000 cm

Package 2 length

80.000 cm

Package 2 weight

40.000 kg

Packaging made with recycled cardboard

Yes

Packaging without single use plastic

No

Scip number

0a787687-ca4b-4982-8684-548a3b52ac76

Product contributes to saved and avoided emissions

No

Carbon footprint (kg.eq.co2 per cr, total life cycle)

0.7555449065230018
