Specifications
Design
Product brand
Clipsal
Range of product
Blue Point
Physical
[in] rated current
5 A
Connector type
- 1 screw terminals
- 2 screw terminals
Number of poles
12
Mounting support
panel
Width
grid pattern: 16 mm
Length
97 mm
Ambient air temperature for operation
120 °C
Standards
CS/840/N
Reach free of svhc
Yes
Mercury free
Yes
Rohs exemption information
Yes
Environmental disclosure
ENVPEP121019EN
Eu rohs directive
Compliant
China rohs regulation
Pro-active China RoHS declaration (out of China RoHS legal scope)
Material
Material
nylon: insulation
Others
Package 1 bare product quantity
1
Outside of Europe
Weee label
N/A
Legacy weee scope
In
Cable cross section
4 mm² fine stranded without cable end sleeve
Minimum mounting height
13 mm
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 weight
0.029 kg
Sustainable packaging
No
End of life manual availability
N/A
Warranty (in months)
18
