Specifications
Design
| Product brand | Clipsal |
|---|---|
| Range of product | Blue Point |
Physical
| [in] rated current | 30 A |
|---|---|
| Connector type |
|
| Number of poles | 12 |
| Mounting support | panel |
| Width | grid pattern: 29 mm |
| Length | 178 mm |
| Ambient air temperature for operation | 190 °C |
| Standards | CS/840/N |
| Mercury free | Yes |
| Rohs exemption information | Yes |
| Environmental disclosure | ENVPEP1210019EN |
| China rohs regulation | Product out of China RoHS scope |
| Eu rohs directive | Compliant By Exemption |
Material
| Material | phenolic: insulation |
|---|
