Clipsal - Max 4 Miniature Circuit Breaker 1.5 Module, 1 Pole, 100A, 27mm, 240V, 10kA
Item Number: 4CB1100D10
Specifications
Design
| Product brand | Clipsal |
|---|
Physical
| Number of poles | 1 |
|---|---|
| [in] rated current | 100 A |
| [ue] rated operational voltage | 240 V |
| Mechanical durability | 20000 cycles |
| Electrical durability | 5000 cycles |
| Connections - terminals |
|
| Wire stripping length | 15 mm |
| Ip degree of protection |
|
| Ambient air temperature for operation | -25...70 °C |
| Ambient air temperature for storage | -40...70 °C |
| Standards | AS/NZS 60898 |
| Relative humidity | 95 % at 55 °C |
| Height | 91 mm |
| Width | 27 mm |
| Depth | 78.5 mm |
| Net weight | 205 g |
| Reach free of svhc | Yes |
| Toxic heavy metal free | Yes |
| Mercury free | Yes |
| Rohs exemption information | Yes |
| Environmental disclosure | ENVPEP121230EN |
| Eu rohs directive | Compliant |
