Datasheet
Close
Specifications
Design
Product brand
Clipsal
Product or component type
switch disconnector
Physical
[ue] rated operational voltage
<= 250 V AC
[in] rated current
100 A
Number of poles
1
Mounting support
DIN rail
Ip degree of protection
front face: IP20
Eu rohs directive
Under investigation
Others
Package 1 bare product quantity
1
Rated conditional short-circuit current
10 kA
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
8.5 cm
Package 1 width
1.8 cm
Package 1 length
7.5 cm
Package 1 weight
80.0 g
