Clipsal - Max 4 DIN Rail Mount Isolators, 3 Pole, 3 Modules, 54mm, 415V, 40A
Item Number: 4PSW340
Datasheet
Close
Specifications
Design
Range of product
Series 4
Product brand
Clipsal
Product or component type
switch disconnector
Physical
[ue] rated operational voltage
<= 415 V AC
[in] rated current
40 A
Number of poles
3
Mounting support
DIN rail
Ip degree of protection
front face: IP20
Reach free of svhc
Yes
Toxic heavy metal free
Yes
Mercury free
Yes
Rohs exemption information
Yes
Environmental disclosure
ENVPEP110309EN
Eu rohs directive
Compliant
China rohs regulation
Pro-active China RoHS declaration (out of China RoHS legal scope)
Others
Weee label
N/A
Outside of Europe
Legacy weee scope
In
Unit type of package 1
PCE
Number of units in package 1
1
Sustainable packaging
No
Packaging made with recycled cardboard
Yes
End of life manual availability
ENVEOLI1103009EN
Warranty (in months)
18
