Clipsal - Max 4 DIN Rail Mount Isolators, 1 Pole, 1 Module, 18mm, 240V, 40A
Item Number: 4PSW140
Datasheet
Close
Specifications
Design
Range of product
Series 4
Product brand
Clipsal
Product or component type
switch disconnector
Physical
[ue] rated operational voltage
<= 240 V AC
[in] rated current
40 A
Number of poles
1
Mounting support
DIN rail
Ip degree of protection
front face: IP20
Reach free of svhc
Yes
Toxic heavy metal free
Yes
Mercury free
Yes
Rohs exemption information
Yes
Environmental disclosure
ENVPEP110309EN
Eu rohs directive
Compliant
China rohs regulation
Product out of China RoHS scope
Eu rohs directive
Compliant
China rohs regulation
Pro-active China RoHS declaration (out of China RoHS legal scope)
Others
Legacy weee scope
In
Package 1 bare product quantity
1
Outside of Europe
Warranty duration(in months) bmecat
18
Weee label
N/A
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
8 cm
Package 1 width
8.7 cm
Package 1 length
1.8 cm
Package 1 weight
77 g
Sustainable packaging
No
China rohs label
1
End of life manual availability
ENVEOLI1103009EN
Warranty (in months)
18
