Acti9 SAU Chassis 250A, 3*(1Ph+N), 32 poles, 18mm for iC60 MCB and RCBO, dual feed

Item Number: SAU2503241NDF

1 PCE 0

Where To Buy

Datasheet

Download

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	3606481908469	-

Specifications

Design

Range	Acti9
Product or component type	chassis
Device application	distribution

Physical

Range compatibility	Acti9 distribution board
[in] rated current	250 A
Rated voltage	415 V AC 500 V DC
Number of poles	32
Number of poles	32 x 18 mm
Width	215 mm
Length	290 mm
Standards	AS/NZS 61439
Mercury free	Yes
Rohs exemption information	Yes
Eu rohs directive	Compliant By Exemption
California proposition 65	WARNING: This product can expose you to chemicals including: Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Others

Legacy weee scope	Out
Package 1 bare product quantity	1
Average percentage of bio-based plastic content	0 %
Average percentage of recycled plastic content	0 %
	Outside of Europe
Warranty duration(in months) bmecat	18
Weee label	N/A
Weee applicability	Finished product
Busbar type	standard
Network type	AC
Number of ways	1 way (incomer) - 1P + N
Short-circuit withstand	25 kA 0.1 s
[ui] rated insulation voltage	500 V
[uimp] rated impulse withstand voltage	6 kV
Busbar pitch	18 mm
Location of connection	dual feed
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	8.5 cm
Package 1 width	25.0 cm
Package 1 length	60.5 cm
Package 1 weight	3510.0 g
Sustainable packaging	No
Pvc free	No
Energy efficiency optimized	False
F-gas free	N/A
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	No
Packaging without single use plastic	No
Pvc free	No
Take-back	No
Warranty (in months)	18
