Acti9 MB Isobar standard distribution board 72 poles, 160A main switch, 18mm, IP42, grey

Item Number: MB272EM1

1 PCE 0

Where To Buy

Datasheet

Download

Product Dimensions

Width580 mm

Height1200 mm

Depth235 mm

See full specifications

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	3606481022554	-

Specifications

Design

Range	Acti9
Product or component type	distribution board
Device application	distribution

Physical

Provided equipment	pole filler circuit schedule card enclosure door DIN rail removable gland plates keys chassis 2 earth/neutral terminal block - top and bottom 165 A main switch
[ue] rated operational voltage	415 V
[ie] rated operational current	160 A
Number of poles	72 x 18 mm
Height	1200 mm
Width	580 mm
Depth	235 mm
Ip degree of protection	IP42

Others

Package 1 bare product quantity	1
Average percentage of bio-based plastic content	0 %
Average percentage of recycled plastic content	0 %
	Outside of Europe
Warranty duration(in months) bmecat	18
Product name	Acti9 isobar DB
Device short name	MB
Enclosure type	standard
Door type	external plain
Network frequency	50 Hz
Breaking capacity	25 kA
[ui] rated insulation voltage	500 V
[uimp] rated impulse withstand voltage	6 kV
Enclosure mounting	surface
Poles description	3P + N
Enclosure material	steel
Enclosure material	steel
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	25.0 cm
Package 1 width	60.0 cm
Package 1 length	125.0 cm
Package 1 weight	60.0 kg
Sustainable packaging	No
Energy efficiency optimized	False
F-gas free	N/A
Average percentage of recycled metal content	0 %
Warranty (in months)	18
