Acti9 Isobar P Isobar A neutral bar 1N, for distribution board, 4 ways SP+N

Item Number: SEA9NKIT

1 PCE 0

This Acti9 Isobar A accessory is a neutral bar. This neutral bar is dedicated for Acti9 Isobar A distribution board with 4 ways.

Where To Buy

Datasheet

Download

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	5018934976563	-

Specifications

Design

Range of product	Acti9
Product or component type	neutral bar
Surface treatment	epoxy
Surface finish	powder paint
Product destination	distribution board

Physical

[ie] rated operational current	250 A at 230/240 V AC 250 A at 110 V AC
Provided equipment	neutral bar busbar link 4 cover
Ip degree of protection	IP2X internal conforming to BS EN 60529
Ik degree of protection	IK05 conforming to BS EN 60529
Standards	BS EN 60439-3
Ambient air temperature for operation	-35...70 °C
Ambient air temperature for storage	-40...80 °C
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP1809003EN
Eu rohs directive	Compliant By Exemption

Others

Life cycle assessment data	Yes
Legacy weee scope	Out
Package 1 bare product quantity	1
Package 2 bare product quantity	50
Package 3 bare product quantity	800
Average percentage of recycled plastic content	0 %
	At least in Europe
Warranty duration(in months) bmecat	18
Weee label	No
Weee applicability	Component
Weee exclusion rationale	Component not in scope – non independent function
Enclosure type	standard
Enclosure mounting	wall mounted
Door type	overall
Enclosure material	steel
Poles description	3P + N
Breaking capacity	25 kA
Protection device name	iC60H
Number of ways	4 ways outgoer
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	2.000 cm
Package 1 width	9.800 cm
Package 1 length	15.600 cm
Package 1 weight	89.000 g
Unit type of package 2	CAR
Number of units in package 2	50
Package 2 height	22.500 cm
Package 2 width	28.000 cm
Package 2 length	34.500 cm
Package 2 weight	4.600 kg
Unit type of package 3	P06
Number of units in package 3	800
Package 3 height	75.000 cm
Package 3 width	80.000 cm
Package 3 length	60.000 cm
Package 3 weight	84.000 kg
Green premium status for reporting	Green Premium product
Total lifecycle carbon footprint	19 kg CO2 eq.
Carbon footprint of the manufacturing phase [a1 to a3]	0.433927846140286
Carbon footprint of the manufacturing phase [a1 to a3]	0.4 kg CO2 eq.
Carbon footprint of the distribution phase [a4]	0.0208357658159405
Carbon footprint of the distribution phase [a4]	0 kg CO2 eq.
Carbon footprint of the installation phase [a5]	0.00350389469242
Carbon footprint of the installation phase [a5]	0 kg CO2 eq.
Carbon footprint of the use phase [b2, b3, b4, b6]	18.493003159871
Carbon footprint of the use phase [b2, b3, b4, b6]	18 kg CO2 eq.
Sustainable packaging	No
Carbon footprint of the end-of-life phase [c1 to c4]	0.236417342876575
Carbon footprint of the end-of-life phase [c1 to c4]	0.2 kg CO2 eq.
Pvc free	No
Silicone-free	No
Energy efficiency optimized	False
F-gas free	N/A
Updatability	N/A
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Total lifecycle carbon footprint	19.1876880093963
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	No
Packaging without single use plastic	No
Pvc free	No
Silicone-free	No
End of life manual availability	N/A
Take-back	No
Warranty (in months)	18
