Acti9 Control and remote indication with Ti24 connector
Item Number: A9C15424
This Acti9 iATL24 product is reliable control and remote indication with Ti24 connector auxiliary. Is operates with 230VAC control voltage. Mounting is performed between 2 iTL impulse relay with yellow clips. The degree of protection is IP20 and IP40 in an enclosure. It is DIN rail mountable. It is associated with iTL impulse relays to allow remote indication of their operating state. This product is compliant with IEC 60947-1 appendix S.
Specifications
Design
Range of product
Range
Product or component type
Product compatibility
- Acti 9 Smartlink
- iTL (32 A) - 230/240 V 50 Hz
- iTL (16 A) - 230/240 V 50 Hz
Market segment
Warranty
Physical
Control type
Power consumption in w
Mounting mode
Mounting support
Electrical durability
Height
Width
Depth
Connections - terminals
- power supply: tunnel type terminals 1 cable(s) 0.5-10 mm² - rigid
- power supply: tunnel type terminals 1 cable(s) 0.5-6 mm² - flexible
- power supply: tunnel type terminals 1 cable(s) 0.5-4 mm² - flexible with ferrule
- input: tunnel type terminals 2 cable(s) 0.5-2.5 mm² - rigid
- input: tunnel type terminals 2 cable(s) 0.5-2.5 mm² - flexible
- input: tunnel type terminals 2 cable(s) 0.5-2.5 mm² - flexible with ferrule
- Ti24 interface: spring-loaded terminal Ti24 2 cable(s) 0.5-1.5 mm² - rigid
- Ti24 interface: spring-loaded terminal Ti24 1 cable(s) 0.5-1.5 mm² - flexible
Wire stripping length
- power supply: 9 mm for bottom connection
- input: 9 mm for bottom connection
- Ti24 interface: 10 mm for top connection
Range compatibility
- Acti9 iTL
- Acti9 iTLi
- Acti9 iTLs
- Acti9 iTLc
Ip degree of protection
- IP20 conforming to IEC 60529
- IP40 (modular enclosure) conforming to IEC 60529
Relative humidity
Ambient air temperature for operation
Ambient air temperature for storage
Standards
Mercury free
Rohs exemption information
Environmental disclosure
Eu rohs directive
Reach regulation
China rohs regulation
Others
Package 1 bare product quantity
Package 2 bare product quantity
Legacy weee scope
Weee label
Average percentage of recycled plastic content
Device short name
Signal contacts composition
Signalling circuit voltage
[uc] control circuit voltage
- 230 V AC 50/60 Hz impulse >= 200 ms
- 24 V DC falling edge
- 24 V DC rising edge
[us] rated supply voltage
[ui] rated insulation voltage
[uimp] rated impulse withstand voltage
Comb busbar and distribution block compatibility
- bottom: YES
- top: NO
Immunity to microbreaks
Undervoltage behaviour
Total power losses
Power losses per pole
9 mm pitches
Tightening torque
- power supply: 1 N.m bottom
- input: 1 N.m bottom
Compatibility code
Overvoltage category
Pollution degree
Tropicalisation
Quality labels
Unit type of package 1
Number of units in package 1
Package 1 height
Package 1 width
Package 1 length
Package 1 weight
Unit type of package 2
Number of units in package 2
Package 2 height
Package 2 width
Package 2 length
Package 2 weight
Green premium status for reporting
Total lifecycle carbon footprint
Carbon footprint of the manufacturing phase [a1 to a3]
Carbon footprint of the manufacturing phase [a1 to a3]
Carbon footprint of the distribution phase [a4]
Carbon footprint of the distribution phase [a4]
Carbon footprint of the installation phase [a5]
Carbon footprint of the installation phase [a5]
Carbon footprint of the use phase [b2, b3, b4, b6]
Carbon footprint of the use phase [b2, b3, b4, b6]
Sustainable packaging
Carbon footprint of the end-of-life phase [c1 to c4]
Carbon footprint of the end-of-life phase [c1 to c4]
Energy efficiency optimized
Take-back
Product contributes to saved and avoided emissions
Removable battery
Total lifecycle carbon footprint
Bvb
Average percentage of recycled metal content
Packaging made with recycled cardboard
Packaging without single use plastic
Scip number
End of life manual availability
Take-back
Weee label
Warranty (in months)
