Acti9 Contactor ICT 100A 4NO 220...240V 50Hz

Item Number: A9C20884

1 PCE 0

Where To Buy

Datasheet

Download

Product Dimensions

Width108 mm

Height85 mm

Depth60 mm

See full specifications

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	3606480375200	-
2	BB1	13606480375207	-

Specifications

Design

Range of product	iCT
Range	Acti9
Product or component type	contactor
Device application	heating-low inductive load
Product compatibility	iACTp iACTs iATEt iACTc
Market segment	small commercial residential
Warranty	18 months

Physical

[ie] rated operational current	100 A AC-7A
Control type	remote control
[ue] rated operational voltage	400 V AC 50 Hz
Control signal type	maintained
Local signalling	action indicator
Mounting mode	clip-on
Mounting support	35 mm symmetrical DIN rail
Height	85 mm
Width	108 mm
Depth	60 mm
Electrical durability	30000 cycles EN 61095 400 V 16 A AC 50 Hz AC-7A 30000 cycles UTE C 61-481 400 V 6 A AC 50 Hz AC-7A 30000 cycles IEC 61095 400 V AC 50 Hz AC-7A
Connections - terminals	control circuit: tunnel type terminals2 cable(s) 1.5-1.5 mm² rigid control circuit: tunnel type terminals1 cable(s) 1.5-2.5 mm² rigid control circuit: tunnel type terminals2 cable(s) 1.5-2.5 mm² flexible power circuit: tunnel type terminals1 cable(s) 6-35 mm² solid or flexible
Standards	EN 61095 IEC 61095 UTE C 61-481
Ip degree of protection	IP20 conforming to IEC 60529 IP40 (modular enclosure) conforming to IEC 60529
Relative humidity	95 % at 55 °C
Ambient air temperature for operation	-5...60 °C
Ambient air temperature for storage	-40...70 °C
Toxic heavy metal free	Yes
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP1103008EN
Reach regulation	Reference contains Substances of Very High Concern above the threshold
China rohs regulation	X
Eu rohs directive	Compliant

Others

Package 1 bare product quantity	1
Package 2 bare product quantity	2
Package 3 bare product quantity	16
Legacy weee scope	In
	At least in Europe
Average percentage of recycled plastic content	0 %
Warranty duration(in months) bmecat	18
Weee label	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Product name	Acti9 iCT
Device short name	iCT
Poles description	4P
Pole contact composition	4 NO
Network type	AC
Utilisation category	AC-1 conforming to EN 60947-4-1 AC-7A conforming to EN 61095 AC-7A conforming to IEC 61095 AC-7A conforming to UTE C 61-481 AC-1 conforming to IEC 60947-4-1
[uc] control circuit voltage	220...240 V AC 50 Hz
Network frequency	50 Hz
Maximum power	AC-7A: 4.2 W at 400 V AC 50 Hz
[ui] rated insulation voltage	500 V AC 50 Hz
[uimp] rated impulse withstand voltage	4 kV
Switching frequency	100 switching operations/day
Hold-in power consumption in va	13 VA
Inrush power in va	106 VA
9 mm pitches	12
Total power losses	27 W
Power losses per pole	9 W
Tightening torque	power circuit: 3.5...3.5 N.m control circuit: 0.8...0.8 N.m A1 / A2
Compatibility code	iCT
Noise level	30 dB
Heat dissipation	4.2...4.2 W at 50/60 Hz
Pollution degree	2
Tropicalisation	2 conforming to EN 60947-4-1
Operating altitude	2000 m
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	6.800 cm
Package 1 width	8.800 cm
Package 1 length	10.900 cm
Package 1 weight	621.000 g
Unit type of package 2	BB1
Number of units in package 2	2
Package 2 height	8.300 cm
Package 2 width	9.800 cm
Package 2 length	23.200 cm
Package 2 weight	1.304 kg
Unit type of package 3	S03
Number of units in package 3	16
Package 3 height	30.000 cm
Package 3 width	30.000 cm
Package 3 length	40.000 cm
Package 3 weight	10.919 kg
Green premium status for reporting	Green Premium product
Total lifecycle carbon footprint	54 kg CO2 eq.
Carbon footprint of the manufacturing phase [a1 to a3]	3.4141737986809226
Carbon footprint of the manufacturing phase [a1 to a3]	3 kg CO2 eq.
Carbon footprint of the distribution phase [a4]	0.10450729807619732
Carbon footprint of the distribution phase [a4]	0.1 kg CO2 eq.
Carbon footprint of the installation phase [a5]	0.07803315416619769
Carbon footprint of the installation phase [a5]	0.1 kg CO2 eq.
Carbon footprint of the use phase [b2, b3, b4, b6]	50.015845776557285
Carbon footprint of the use phase [b2, b3, b4, b6]	50 kg CO2 eq.
Sustainable packaging	No
Carbon footprint of the end-of-life phase [c1 to c4]	0.8180806396119752
Carbon footprint of the end-of-life phase [c1 to c4]	0.8 kg CO2 eq.
Pvc free	Yes
Halogen-free status	Product contains halogen above thresholds
Energy efficiency optimized	False
F-gas free	N/A
Updatability	N/A
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Total lifecycle carbon footprint	54.43064066709258
Bvb	Accepted
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	No
Packaging without single use plastic	No
Scip number	6763a476-30bc-4d05-a4bb-93f8d65c3771
China rohs label	1
Halogen-free status	Product contains halogen above thresholds
Pvc free	Yes
End of life manual availability	N/A
Take-back	No
Weee label	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Warranty (in months)	18
