Specifications
Design
| Range | Acti9 |
|---|---|
| Product or component type | relay |
| Market segment |
|
| Warranty | 18 months |
Physical
| [ie] rated operational current |
|
|---|---|
| Local signalling | LED, flashing for time delay |
| Type of setting | rotary knob: time delay configuration |
| Mounting mode | fixed |
| Mounting support | 35 mm symmetrical DIN rail |
| Height | 93 mm |
| Width | 18 mm |
| Depth | 72 mm |
| Net weight | 0.065 kg |
| Mechanical durability | 5000000 cycles |
| Electrical durability | AC-1: 100000 cycles |
| Connections - terminals |
|
| Ip degree of protection | IP20 |
| Ambient air temperature for operation | -5...55 °C |
| Ambient air temperature for storage | -40...70 °C |
| Mercury free | Yes |
| Rohs exemption information | Yes |
| Environmental disclosure | ENVPEP1211017EN |
| Reach regulation | Reference contains Substances of Very High Concern above the threshold |
| China rohs regulation | X |
| Eu rohs directive | Compliant By Exemption |
| California proposition 65 | WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
