Specifications
Design
Range of product
OptiLine 50
Product or component type
cable shelf
Colour tint
white (RAL 9010)
Warranty
18 months
Physical
Quantity per set
24 m
Fixing mode
snap-fitted
Length
1000 mm
Height
17 mm
Width
48 mm
Ambient air temperature for operation
-25...60 °C
Ip degree of protection
IP40
Ik degree of protection
IK07
Reach free of svhc
Yes
Toxic heavy metal free
Yes
Mercury free
Yes
Rohs exemption information
Yes
Environmental disclosure
ENVPEP090918EN
Eu rohs directive
Pro-active compliance (Product out of EU RoHS legal scope)
China rohs regulation
Pro-active China RoHS declaration (out of China RoHS legal scope)
Material
Material
PC/ABS
Others
Legacy weee scope
Out
Package 1 bare product quantity
1
At least in Europe
Weee label
No
Trunking material
- plastic
- aluminium
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
1.7 cm
Package 1 width
4.8 cm
Package 1 length
100 cm
Package 1 weight
88 g
Sustainable packaging
No
End of life manual availability
N/A
Warranty (in months)
18
