Canalis KBA Universal fixing bracket 25 A and 40 A, suspended on threaded rod or lateral, galvanized version

Item Number: KBA40ZFU

1 PCE 0

Where To Buy

Datasheet

Download

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	3606480000621	-
10	BAG	23606480000625	-

Specifications

Design

Range	Canalis
Range of product	Canalis
Product or component type	bracket
Product compatibility	KBA
Warranty	18 months

Physical

Standards	IEC 61439-6
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP2404009EN
Reach regulation	Reference contains Substances of Very High Concern above the threshold
China rohs regulation	Product out of China RoHS scope
Eu rohs directive	Compliant By Exemption
California proposition 65	WARNING: This product can expose you to chemicals including: Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
California proposition 65	WARNING: This product can expose you to chemicals including: Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Others

Life cycle assessment data	No
If one of the deliverables is not relevant please give the reason	PEP created standard configuration(Canalis KBA), but individual CR is component
Substance regulation data deliverable	Yes
Package 1 bare product quantity	1
Legacy weee scope	In
Package 2 bare product quantity	10
Package 3 bare product quantity	200
Package 4 bare product quantity	3200
Average percentage of recycled plastic content	0 %
	At least in Europe
Warranty duration(in months) bmecat	18
Weee label	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Fixing device mounting	suspended on threaded rod
Maximum load	60 kg
Accessory / separate part category	fixing accessory
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	2.000 cm
Package 1 width	3.800 cm
Package 1 length	7.000 cm
Package 1 weight	33.900 g
Unit type of package 2	BB1
Number of units in package 2	10
Package 2 height	4.000 cm
Package 2 width	14.500 cm
Package 2 length	11.000 cm
Package 2 weight	340.000 g
Unit type of package 3	CAR
Number of units in package 3	200
Package 3 height	18.000 cm
Package 3 width	24.500 cm
Package 3 length	38.000 cm
Package 3 weight	7.310 kg
Sustainable packaging	No
Pvc free	Yes
Halogen-free status	Halogen free product
Silicone-free	Yes
F-gas free	N/A
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	Yes
Packaging without single use plastic	Yes
Scip number	92700f7b-078c-4f59-92c9-f4ad9263c3bd
Halogen-free status	Halogen free product
Pvc free	Yes
Silicone-free	Yes
End of life manual availability	N/A
Take-back	No
Weee label	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Warranty (in months)	18

Show all specifications
