Airflow Exhaust fan ceiling, 250mm blade dia, white

Item Number: CE250N

1 PCE 0

Where To Buy

Datasheet

Download

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	3606486373903	-

Specifications

Design

Range of product	Airflow
Range	Airflow
Product brand	Clipsal
Product or component type	exhaust fan
Product destination	ceiling fitting
Warranty	3 Years

Physical

Provided equipment	fan 110 mm 250 mm
[ue] rated operational voltage	230 V AC 50 Hz
Power consumption in w	40 W
[in] rated current	0.32 A full load
Depth	110 mm
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP2302013_V2
Eu rohs directive	Compliant By Exemption

Material

Material	ABS (acrylonitrile butadiene-styrene)

Others

Legacy weee scope	In
Package 1 bare product quantity	1
Package 2 bare product quantity	5
Package 3 bare product quantity	40
Average percentage of recycled plastic content	0 %
	Outside of Europe
Warranty duration(in months) bmecat	36
Weee label	N/A
Weee applicability	Finished product
Main colour tint	white
Air flow	358 m3/h
Diameter	345 mm impeller:
Motor type	ball bearing
Number of blades	3
Noise level	44 dB
Fan type	axial
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	35.5 cm
Package 1 width	12 cm
Package 1 length	35.5 cm
Package 1 weight	1.492 kg
Unit type of package 2	CAR
Number of units in package 2	5
Package 2 height	37.3 cm
Package 2 width	39 cm
Package 2 length	63 cm
Package 2 weight	8.48 kg
Unit type of package 3	PAL
Number of units in package 3	40
Package 3 height	95 cm
Package 3 width	113 cm
Package 3 length	113 cm
Package 3 weight	94 kg
Green premium status for reporting	Green Premium product
Total lifecycle carbon footprint	322 kg CO2 eq.
Carbon footprint of the manufacturing phase [a1 to a3]	7.004548832625229
Carbon footprint of the manufacturing phase [a1 to a3]	7 kg CO2 eq.
Carbon footprint of the distribution phase [a4]	0.4321818254465059
Carbon footprint of the distribution phase [a4]	0.4 kg CO2 eq.
Carbon footprint of the installation phase [a5]	0.41766580983711366
Carbon footprint of the installation phase [a5]	0.4 kg CO2 eq.
Carbon footprint of the use phase [b2, b3, b4, b6]	311.39
Carbon footprint of the use phase [b2, b3, b4, b6]	311 kg CO2 eq.
Sustainable packaging	No
Carbon footprint of the end-of-life phase [c1 to c4]	3.176036652770934
Carbon footprint of the end-of-life phase [c1 to c4]	3 kg CO2 eq.
Pvc free	No
Silicone-free	No
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Total lifecycle carbon footprint	322.4204331206798
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	No
Packaging without single use plastic	No
Pvc free	No
Silicone-free	No
End of life manual availability	N/A
Take-back	No
Warranty (in months)	36
