Metal Plate Series Twin Switch Socket Outlet 250V, 10A, A Style, Deep Curve Plate, Extra Switch | Black
Item Number: BA25X-BK
Datasheet
Close
Specifications
Design
Range of product
Metal Plate
Product or component type
switched socket
Product brand
Clipsal
Physical
Control type
ON/OFF button
Number of gangs
2 gangs
Pin number
3
Number of power socket outlets
2
Actuator
- switch
- rocker
Fixing mode
by screws
Local signalling
without light indicator
Mounting position
horizontal
[ue] rated operational voltage
250 V AC
[in] rated current
10 A
Depth
28 mm
Length
130 mm
Width
86 mm
Fixing center
84 mm
Standards
- AS/NZS 3100
- AS/NZS 3112
- AS/NZS 3133:approval number S/1
Environmental disclosure
ENVPEP120506EN
Eu rohs directive
Compliant with Exemptions
China rohs regulation
Product out of China RoHS scope. Substance declaration for your information
Material
Material
brass
Others
Legacy weee scope
In
Weee label
N/A
Outside of Europe
Package 1 bare product quantity
1
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
2.8 cm
Package 1 width
8.6 cm
Package 1 length
13.0 cm
Package 1 weight
0.225 kg
Sustainable packaging
No
End of life manual availability
N/A
Warranty (in months)
18
