Harmony eXLhoist System with charger standard, shoulder belt, cable USB/RJ45 and config software

Item Number: XARSK8D18W

Where To Buy

Datasheet

PDF datasheet

Download

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range of product

Harmony eXLhoist

Product or component type

control station

Physical

Number of channels

50

Operating distance

100 m in free air

Cable entry

cable gland

Communication network type

wireless: bluetooth low energy

Transmission frequency

2.4 GHz

Relative humidity

0...95 % at -20...45 °C storage

Standards

  • IEC 60204-1 safety
  • ISO 13849-1 safety
  • IEC 62061 safety
  • IEC 61508 safety
  • ISO 13850 safety
  • IEC 60204-32 hoisting applications
  • ETSI EN 301 489-1 radio
  • ETSI EN 301 489-3 radio
  • ETSI EN 301 489-17 radio
  • ETSI EN 300 440-2 radio
  • ETSI EN 300 328 radio
  • FCC part 15 radio
  • RSS GEN issue 3 radio
  • RSS 210 issue 8 radio
  • ARIB STD-T81 radio

Product certifications

  • CE
  • UL
  • CSA
  • C-Tick
  • JIS
  • KC
  • EAC

Mercury free

Yes

Rohs exemption information

Yes

Environmental disclosure

ENVPEP1403029EN

Eu rohs directive

Pro-active compliance (Product out of EU RoHS legal scope)

Reach regulation

Reference contains Substances of Very High Concern above the threshold

China rohs regulation

X

California proposition 65

WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Others

Average percentage of recycled plastic content

0 %

Package 2 bare product quantity

2

Package 1 bare product quantity

1

Legacy weee scope

In

At least in Europe

Weee label

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins

Device short name

XARS

Control station type

wireless

Product specific application

  • hoisting applications
  • material handling

Control station application

  • stop function: SIL 2 maximum (can reach PL d/category 3) conforming to IEC 62061
  • stop function: SIL 2 maximum (can reach PL d/category 3) conforming to ISO 13849-1
  • emergency stop function: SIL 3 maximum (can reach PL e/category 4) conforming to IEC 62061
  • emergency stop function: SIL 3 maximum (can reach PL e/category 4) conforming to ISO 13849-1
  • motion function: SIL 1 maximum (can reach PL c/category 1) conforming to IEC 62061
  • motion function: SIL 1 maximum (can reach PL c/category 1) conforming to ISO 13849-1
  • limiter protection function: SIL 1 maximum (can reach PL c/category 1) conforming to IEC 62061
  • limiter protection function: SIL 1 maximum (can reach PL c/category 1) conforming to ISO 13849-1

Kit composition

  • remote control
  • base station
  • shoulder belt
  • cable
  • configuration software

Radio agreement

  • SRRC
  • RSS
  • ARIB
  • ANATEL
  • FCC
  • ICASA

Electromagnetic compatibility

  • resistance to electrostatic discharge - test level: 4 kV class B (on contact) conforming to IEC 61000-4-2
  • resistance to electrostatic discharge - test level: 8 kV class B (in air) conforming to IEC 61000-4-2
  • resistance to radiated electromagnetic fields - test level: 10 V/m class B conforming to IEC 61000-4-3

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

20.500 cm

Package 1 width

29.000 cm

Package 1 length

30.800 cm

Package 1 weight

3.050 kg

Unit type of package 2

S04

Number of units in package 2

2

Package 2 height

30.000 cm

Package 2 width

40.000 cm

Package 2 length

60.000 cm

Package 2 weight

6.884 kg

Sustainable packaging

No

Take-back

No

Product contributes to saved and avoided emissions

No

Removable battery

N/A

Average percentage of recycled metal content

0 %

Packaging made with recycled cardboard

No

Packaging without single use plastic

No

Scip number

6e438e59-42d1-4633-bfe2-cb5ef607659b

End of life manual availability

ENVEOLI1403029EN

Take-back

No

Weee label

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins

Warranty (in months)

18
