Harmony XVB, Indicator bank, illuminated unit, plastic, yellow, 70mm, flashing, for bulb or LED, 24V AC, 24...48V DC

Harmony XVB, Indicator bank, illuminated unit, plastic, yellow, 70mm, flashing, for bulb or LED, 24V AC, 24...48V DC

Item Number: XVBC4B8

This yellow illuminated unit is designed to be connected with base to create complete tower light. Its integral LED offers a steady light, allowing it to clearly display the status of your machines. In applications such as automotive, machine tool, material handling, packaging, assembly stations, conveyors. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66. It makes it ideal for operation in harsh environments.

Datasheet

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range of product

Harmony XVB Universal

Product or component type

indicator bank

Warranty

18 months

Physical

Connections - terminals

screw clamp terminals, <= 1 x 1.5 mm² with cable end

Net weight

0.16 kg

Product certifications

CCC|EAC|CSA C22-2 No 14|UL 508

Standards

IEC 60947-5-1

Ambient air temperature for storage

-40...70 °C

Ambient air temperature for operation

-25...50 °C: incandescent|-25...50 °C: LED

Ip degree of protection

IP65 on fixing base XVBZ0. conforming to IEC 60529|IP66 on base unit conforming to IEC 60529

Reach regulation

Reference contains Substances of Very High Concern above the threshold

Eu rohs directive

Pro-active compliance (Product out of EU RoHS legal scope)

Mercury free

Yes

China rohs regulation

X

Rohs exemption information

Yes

Environmental disclosure

ENVPEP070907EN

Circularity profile

N/A

California proposition 65

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Material

Material

polycarbonate

Others

Commercial status history

SESA301466 | Fri Oct 25 03:41:00 EDT 2024 | From Import Local | From 08 to 14

Package 1 bare product quantity

1

Packaging made with recycled cardboard

No

Packaging without single use plastic

No

Beacon or indicator bank unit type

illuminated unit

Signalling type

flashing

Mounting diameter

70 mm

Component name

XVBC

Light source

bulb not included, yellow

Bulb type

incandescent with BA 15d base|protected LED|incandescent

[us] rated supply voltage

24 V AC|24...48 V DC

Assembly style

customer assembly, up to 5 units

Maximum power dissipation in w

7 W

[ui] rated insulation voltage

250 V conforming to IEC 60947-1

Nominal voltage limit

0.85...1.1 Un conforming to IEC 60947-5-1

[uimp] rated impulse withstand voltage

4 kV conforming to IEC 60947-1

Flashing frequency

1 Hz

Cad overall width

70 mm

Cad overall height

63 mm

Cad overall depth

70 mm

Pollution degree

2

Protective treatment

TC

Electrical shock protection class

class I on support tube conforming to IEC 61140|class II on base unit conforming to IEC 61140

Nema degree of protection

Type 4X conforming to UL (indoor)

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

8.0 cm

Package 1 width

8.0 cm

Package 1 length

9.3 cm

Package 1 weight

144.0 g

Unit type of package 2

S03

Number of units in package 2

36

Package 2 height

30.0 cm

Package 2 width

30.0 cm

Package 2 length

40.0 cm

Package 2 weight

5.858 kg

Green premium status for reporting

Green Premium product

Scip number

124e2d7a-5b1e-45ca-b93c-220dd91b55b6

Weee

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins

Take-back

No

Take-back

No

Product contributes to saved and avoided emissions

No

Removable battery

N/A

Carbon footprint (kg.eq.co2 per cr, total life cycle)

73.0213280073
