Harmony XVU Fixing unit for modular tower lights black, 60mm, 2 pins direct mounting

Item Number: XVUZ03

1 PCE 0

Where To Buy

Datasheet

Download

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	3606480711565	-

Specifications

Design

Range of product	Harmony XVU
Product or component type	modular tower light
Product compatibility	top: AC body top: DC body top: swivel mounting support

Physical

Pin number	2
Mounting support	direct mounting
Connections - terminals	push-in
Length	17 mm
Net weight	0.06 kg
Ambient air temperature for storage	-40...70 °C
Ambient air temperature for operation	-25...50 °C
Ip degree of protection	IP65
Product certifications	UL CSA CE
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP2308032EN
Reach regulation	Reference contains Substances of Very High Concern above the threshold
China rohs regulation	X
Eu rohs directive	Compliant By Exemption
California proposition 65	WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Material

Material	PBT (polybutylene terephthalate) V-0 conforming to UL 94 ABS (acrylonitrile butadiene-styrene) PC (polycarbonate)

Others

Legacy weee scope	Out
	At least in Europe
Average percentage of recycled plastic content	0 %
Package 2 bare product quantity	24
Package 1 bare product quantity	1
Warranty duration(in months) bmecat	18
Weee label	No
Accessory / separate part type	mounting plate
Accessory / separate part category	mounting and fixing accessory
Component name	XVU
Mounting diameter	60 mm
Housing colour	black
[us] rated supply voltage	24 V AC/DC 110...240 V AC
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	9.000 cm
Package 1 width	9.000 cm
Package 1 length	13.000 cm
Package 1 weight	155.000 g
Unit type of package 2	S03
Number of units in package 2	24
Package 2 height	30.000 cm
Package 2 width	30.000 cm
Package 2 length	40.000 cm
Package 2 weight	4.281 kg
Green premium status for reporting	Green Premium product
Total lifecycle carbon footprint	0.5 kg CO2 eq.
Carbon footprint of the manufacturing phase [a1 to a3]	0.39436867060820696
Carbon footprint of the manufacturing phase [a1 to a3]	0.4 kg CO2 eq.
Carbon footprint of the distribution phase [a4]	0.007845811625592695
Carbon footprint of the distribution phase [a4]	0 kg CO2 eq.
Carbon footprint of the installation phase [a5]	0.0620558449920974
Carbon footprint of the installation phase [a5]	0.1 kg CO2 eq.
Carbon footprint of the use phase [b2, b3, b4, b6]	0
Carbon footprint of the use phase [b2, b3, b4, b6]	0 kg CO2 eq.
Sustainable packaging	Yes
Carbon footprint of the end-of-life phase [c1 to c4]	0.052288239770532104
Carbon footprint of the end-of-life phase [c1 to c4]	0.1 kg CO2 eq.
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Total lifecycle carbon footprint	0.5165585669964291
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	Yes
Packaging without single use plastic	Yes
Scip number	c06fce4f-aea2-46a5-aadb-0b38d1efbe3f
China rohs label	5
End of life manual availability	ENVEOLI2308032EN
Take-back	No
Warranty (in months)	18
