Harmony XVB Audible unit for modular tower lights plastic, Ø70, buzzer, continuous or intermittent tone,70... 90 dB, 120...230 V AC

Item Number: XVBC9M

1 PCE 0

Where To Buy

Datasheet

Download

Barcode

Qty	UoM	EAN	Colour
			-
			-
			-

Barcode

Qty	UoM	EAN	Colour
1	PCE	3389110845976	-

Specifications

Design

Range of product	Harmony XVB Universal
Product or component type	indicator bank
Warranty	18 months

Physical

Connections - terminals	screw clamp terminals, <= 1 x 1.5 mm² with cable end
Net weight	0.18 kg
Product certifications	CCC EAC CSA C22-2 No 14 UL 508
Standards	IEC 60947-5-1
Ambient air temperature for storage	-40...70 °C
Ambient air temperature for operation	-25...50 °C
Ip degree of protection	IP65 on fixing base XVBZ0. conforming to IEC 60529 IP66 on base unit conforming to IEC 60529
Mercury free	Yes
Rohs exemption information	Yes
Environmental disclosure	ENVPEP0709007EN
Reach regulation	Reference contains Substances of Very High Concern above the threshold
China rohs regulation	X
Eu rohs directive	Compliant By Exemption
California proposition 65	WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Others

Important message	XVB is being substituted by XVB7 as complete range; XVB and XVB7 modules are not interoperable with one another.
Package 1 bare product quantity	1
Legacy weee scope	Out
Average percentage of recycled plastic content	0 %
	At least in Europe
Package 2 bare product quantity	36
Package 3 bare product quantity	144
Weee label	No
Warranty duration(in months) bmecat	18
Beacon or indicator bank unit type	audible unit
Mounting diameter	70 mm
Component name	XVBC
Noise level	70...90 dB at 1 m
[us] rated supply voltage	120...230 V AC
Signalling type	continuous or intermittent buzzer
Assembly style	customer assembly, up to 5 units
[ui] rated insulation voltage	250 V conforming to IEC 60947-1
Nominal voltage limit	0.85...1.1 Un conforming to IEC 60947-5-1
Current consumption	< 25 mA
[uimp] rated impulse withstand voltage	4 kV conforming to IEC 60947-1
Fundamental frequency	2.8 kHz
Cad overall width	70 mm
Cad overall height	63 mm
Cad overall depth	70 mm
Protective treatment	TC
Electrical shock protection class	class I on support tube conforming to IEC 61140 class II on base unit conforming to IEC 61140
Nema degree of protection	Type 4X conforming to UL (indoor)
Unit type of package 1	PCE
Number of units in package 1	1
Package 1 height	10.000 cm
Package 1 width	8.200 cm
Package 1 length	8.000 cm
Package 1 weight	172.000 g
Unit type of package 2	S03
Number of units in package 2	36
Package 2 height	30.000 cm
Package 2 width	30.000 cm
Package 2 length	40.000 cm
Package 2 weight	7.000 kg
Unit type of package 3	P06
Number of units in package 3	144
Package 3 height	45.000 cm
Package 3 width	60.000 cm
Package 3 length	80.000 cm
Package 3 weight	36.500 kg
Green premium status for reporting	Green Premium product
Total lifecycle carbon footprint	173 kg CO2 eq.
Carbon footprint of the manufacturing phase [a1 to a3]	1.9108907549
Carbon footprint of the manufacturing phase [a1 to a3]	2 kg CO2 eq.
Carbon footprint of the distribution phase [a4]	0.0628558167
Carbon footprint of the distribution phase [a4]	0.1 kg CO2 eq.
Carbon footprint of the installation phase [a5]	0.052576902
Carbon footprint of the installation phase [a5]	0.1 kg CO2 eq.
Carbon footprint of the use phase [b2, b3, b4, b6]	170.559375
Carbon footprint of the use phase [b2, b3, b4, b6]	171 kg CO2 eq.
Sustainable packaging	Yes
Carbon footprint of the end-of-life phase [c1 to c4]	0.3644204397
Carbon footprint of the end-of-life phase [c1 to c4]	0.4 kg CO2 eq.
Take-back	No
Product contributes to saved and avoided emissions	No
Removable battery	N/A
Total lifecycle carbon footprint	172.9501189132
Average percentage of recycled metal content	0 %
Packaging made with recycled cardboard	Yes
Packaging without single use plastic	Yes
Scip number	124e2d7a-5b1e-45ca-b93c-220dd91b55b6
China rohs label	5
End of life manual availability	N/A
Take-back	No
Warranty (in months)	18
