Clipsal - 56 Series Surface Switch 2 Gang Four Pole 63A Base Mount Less Enclosure

Home ProductsIndustrial56 SeriesSurface Switch

Clipsal - 56 Series Surface Switch 2 Gang Four Pole 63A Base Mount Less Enclosure | Grey

Item Number: 56SWHS463LE-GY

Where To Buy

Datasheet

PDF datasheet

Download

Barcode

Qty UoM EAN Colour
-
-
-
See all

Specifications

Design

Range

Clipsal - 56 Series

Product or component type

switch

Colour

cover: chemical grey

Market segment

  • small commercial
  • industry
  • utility

Physical

Control type

rotary knob

[ue] rated operational voltage

500 V AC 50 Hz

Rated current

63 A

Ip degree of protection

IP66 conforming to AS 60529

Standards

AS/NZS 3133

Mercury free

Yes

Rohs exemption information

Yes

Eu rohs directive

Compliant with Exemptions

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Others

Legacy weee scope

In

Package 1 bare product quantity

1

Weee label

N/A

Outside of Europe

Handle colour

grey

Suitability for isolation

yes

Poles description

4P

Tightening torque

0.8 N.m

Breaking capacity

63 kA at 500 V (AC-21A)

Targeted country

Australia

Motor m-rating as3133

M320 at 690 V

Rotary handle padlocking

2 padlocks 8-8 mm

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 weight

0.530 kg

Sustainable packaging

No

Warranty (in months)

18
Show all specifications
