Medilec, Twin Switch Socket Outlet, 250V, 10A, 2 Gang, Safety Shutter

Home ProductsHealth SolutionsMedilecTwin Switch Socket Outlet

Medilec, Twin Switch Socket Outlet, 250V, 10A, 2 Gang, Safety Shutter Red

Item Number: ML2025IS-RD

Datasheet

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range of product

Series ML2000|Medilec

Product or component type

switched socket

Product brand

Clipsal

Surface finish

glossy

Physical

Control type

ON/OFF button

Number of gangs

2 gangs

Pin number

3

Number of power socket outlets

2

Actuator

rocker|switch

Fixing mode

by screws

Local signalling

indicator light

Device mounting

flush

Mounting position

horizontal

[ue] rated operational voltage

250 V

[in] rated current

10 A

Length

116 mm

Width

76 mm

Standards

AS/NZS 3112:approval number S/1/2025|AS/NZS 3112:approval number S/1/2015

Reach regulation

Reference contains Substances of Very High Concern above the threshold

Eu rohs directive

Compliant with Exemptions

Mercury free

Yes

Rohs exemption information

Yes

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Material

Material

plastic

Others

Package 1 bare product quantity

1

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 weight

1.000 kg
