Thorsman installation material, Shield Anchor, M8 x 55mm, set of 100

Thorsman installation material, Shield Anchor, M8 x 55mm, set of 100

Item Number: 1511203

Datasheet

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range of product

Thorsman

Product or component type

anchor

Surface finish

zinc plated

Sustainable offer status

Green Premium product

Warranty

18 months

Physical

Mounting support

brick|rock|concrete|stone

Quantity per set

set of 100

Sale per indivisible quantity

100

Reach regulation

Free of Substances of Very High Concern above the threshold

Reach free of svhc

Yes

Eu rohs directive

Pro-active compliance (Product out of EU RoHS legal scope)

Toxic heavy metal free

Yes

Mercury free

Yes

Rohs exemption information

Yes

China rohs regulation

 Pro-active China RoHS declaration (out of China RoHS legal scope)

Environmental disclosure

ENVPEP101027EN

Circularity profile

N/A

Material

Material

steel

Others

Package 1 bare product quantity

1

Drilling diameter

14 mm

Minimum drilling depth

60 mm

Thread type

M8

Threaded length

55 mm

Practical load capacity

4 kN pull-out load concrete

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

1.3 cm

Package 1 width

1.3 cm

Package 1 length

5 cm

Package 1 weight

24 g

Unit type of package 2

BB1

Number of units in package 2

100

Package 2 height

8 cm

Package 2 width

10.1 cm

Package 2 length

18 cm

Package 2 weight

2.4 kg

Unit type of package 3

CAR

Number of units in package 3

600

Package 3 height

16 cm

Package 3 width

23 cm

Package 3 length

30 cm

Package 3 weight

14.61 kg
