Clipsal Iconic Double Power Point Skin Horizontal Mount, 250V, 10A, Clip-On

Back to Twin Horizontal Mount Home Socket Outlet Skins Twin Horizontal Mount

Vivid White | Clipsal Iconic Double Power Point Skin Horizontal Mount, 250V, 10A, Clip-On

Clipsal Iconic Double Power Point Skin Horizontal Mount, 250V, 10A, Clip-On

Item Number: 3025C-VW

Build your Iconic i

Update the look of your switches and smart power points safety and quickly with the Clipsal Iconic collection. The Clipsal Iconic Double Power Point Skin clips-on to the Double Switched Power Point grid, creating a finished product which is both appealing to look at and smooth to the touch.

Where To Buy

Datasheet

Download

Product Dimensions

Width icon

Width78 mm

Height icon

Height120 mm

Depth icon

Depth12 mm

See full specifications

Barcode

Qty UoM EAN Colour
-
-
-
See all
Clipsal Iconic 3025 exploded view
3043G Rear Perspective
Socket exploded view
Clipsal Iconic 3025 exploded view
3043G Rear Perspective
Socket exploded view

Features

Clever ideas for easy installs

  • All electrical accessories available in the Iconic 40M format

  • Slim 7mm profile blends in with the décor

  • Optional pictogram rockers to personalise switches

  • Translucent edges allow the skin to infuse with the wall colour

Features

Smart Switch Innovation

  • Locking bar helps to reduce the risk of mechanism pushbacks, and makes it easier to change or upgrade mechanisms

  • Metal plate for additional robustness

  • Pre-mounted screws for faster fit-off, O rings prevent screws dislodging during transportation

  • Protective flaps help prevent direct access to the screws after installation

Features

  • Slim, sleek and clean design
  • A soft touch matte finish for a premium look and feel
  • The standard Iconic range of skins offers flexibility with standard white skins, and subtle colour variants that blend with interior décors

Specifications

Design

Range

Clipsal Iconic

Aesthetic name

Iconic

Product or component type

cover frame

Colour tint

vivid white (VW)

Product destination

switched socket

Surface treatment

untreated

Sustainable offer status

Green Premium product

Physical

Type of packing

polybag

Quantity per set

set of 20

Range compatibility

Clipsal Iconic switched socket

Device mounting

flush

Number of rocker

2

Number of power socket outlets

2

[In] rated current

10 A

Installation direction

horizontal

Fixing mode

clip-on

Height

120 mm

Width

78 mm

Depth

12 mm

Net weight

0.02 kg

Ambient air temperature for operation

0...45 °C

Relative humidity

10...95 %

REACh Regulation

Free of Substances of Very High Concern above the threshold

REACh free of SVHC

Yes

EU RoHS Directive

Compliant

Toxic heavy metal free

Yes

Mercury free

Yes

RoHS exemption information

Yes

China RoHS Regulation

 Pro-active China RoHS declaration (out of China RoHS legal scope)

Environmental Disclosure

ENVPEP120506EN

Material

Material

  • PC (polycarbonate): skin
  • ABS (acrylonitrile butadiene-styrene): skin

Others

Package 1 Bare Product Quantity

1

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Height

1 cm

Package 1 Width

7.5 cm

Package 1 Length

11.8 cm

Package 1 Weight

23 g

Unit Type of Package 2

BB1

Number of Units in Package 2

20

Package 2 Height

15 cm

Package 2 Width

10.8 cm

Package 2 Length

22 cm

Package 2 Weight

0.554 kg

Unit Type of Package 3

CAR

Number of Units in Package 3

100

Package 3 Height

33.5 cm

Package 3 Width

26.1 cm

Package 3 Length

33.5 cm

Package 3 Weight

3311.2 g
Show all specifications

Frequently Asked Questions

hide show

Will an Iconic Pro series cover plate fit on an Iconic standard series grid plate?

It will not fit.
Iconic Pro series covers/skins will only fit pro series grid plates for all switches & power points.
This also mean that standard Iconic series covers/skins will not fit pro series grid plates.


. P3025C-BK


Will the Pro series outlets fit in the Tal Plus skirting duct?

No, the Pro series outlets will not fit in the Tal Plus skirting duct.
The power shrouds (PLPSK) are not large enough for the back of the outlet to fit in.

What is the difference between the product code I have ordered and the same product with a ‘Z’ added to the end?

The products are the same but are either in Bluetooth mode or Zigbee out of the box. For example, the 3025CSG connected socket outlet is in Bluetooth and the 3025CSGZ connected socket will be in Zigbee mode.
This is designed to save time on install and commissioning of a Wiser system where the Hub is used. Using a default Zigbee product, means there is no need to go through the process of changing modes from BLE to Zigbee to connect to the Wiser Hub.


I have made name changes to my Wiser devices in Wiser by SE how can I get these changes to work with Google voice control?

When setting up Google home and voice control make sure that any changes that are made to devices in Wiser by SE in the naming of mechs or adding/removing items are done on the device that the speaker is linked within google home. Making sure to refresh the Google Home App after the changes are made in Wiser by SE.

The changes will not be recognized If they are done on a device that is not the creator of the Home within the Google Home App that is linked with the voice control speaker. This can be solved by having the creator refresh his Google Home.
Note: Only one Wiser by SE account should be linked with Google home per household. This person should then create the home within Google Home and add members to this home. If more than one Wiser by SE account in the same home is linked to Google Home this can create ‘doubles’ of the Wiser devices within the Google Home App.


How do I swap my Wiser connected socket outlet from BLE to Zigbee?

If the Socket is currently paired with Wiser by SE, remove/delete the socket from the App. Go to the Bluetooth settings on your phone/device and forget the socket that you just removed from the App.

Download the Wiser Room App, if you don’t have it on your smart device, and open it. Within Wiser Room tap Edit at the top right and select ‘Add New Device’. Follow the instructions and pair your socket with Wiser Room. Once paired in Wiser Room, tap on the socket and then tap on the cog to enter the settings of the device. Tap on Advanced Settings, tap on Device Information and then proceed to update the Firmware of the socket.

Once the firmware update is completed and you can re-connect to the device once again check to make sure there are no more firmware updates. Once confirmed remove the socket from Wiser Room App by tapping Edit in the top right and then delete the device. Open the Bluetooth settings on your phone and once again remove the socket from here.

To then swap the socket from Bluetooth to Zigbee tap the touch switch LED panel 12 times. When the swap is completed you will see both the left and right LED on the panel blinking together indicating you are in Zigbee mode. Tap the touch switch panel to stop the blinking.

In Wiser by SE, go to the home you wish to add the socket to and tap the plus symbol in the top right corner. Go to the Add with Hub option and select the Iconic Socket and follow the instructions, tap the LED panel 3 times as per the animation and confirm that both LED’s on the panel are flashing.


Wiser Product Warranty

The Hub, IR converter and all Sensors have a warranty of 12 months.
The 2AX (41E2PBSWM), 10AX (41E10PBSWM), Dimmer (41EPBDWCLM), Micro module dimmer (CLP5010WDZ), Micro module switch (CLP5011WSZ), Micro module blinds (CLP5015WBZ) and the Connected Socket Outlet (3025CSG) all have a 2-year warranty.
This information can be found on the product installation instructions.


Range

The Clipsal Iconic range is founded on a specialised electrically safe grid plate.
Once installed by an electrician, it’s safe for anyone to change the skins at any time by simply clipping off the standard skins and snapping on a new design.

Iconic’s interchangeable standard, Styl and Essence skins provide clever options tailored to suit a homes’ decor or family’s lifestyle.

Wiser Room app on digital device

Clever Connectivity

ControlLink and Bluetooth Low Energy (BLE) offer complete control of your home lighting via the Wiser Room app on your digital device.
Clipsal Iconic Nightwalk

Night Walk

Make night time navigation safer with Night Walk's soft-glow LED sensor. Or switch to 'night light mode', ideal for kids’ rooms or long corridors.
Clipsal Iconic Essence

Clipsal Iconic Essence

With smooth round wooden curves, its real timber finish set the benchmark for quality and style in residential products, enhancing any living space.
Clipsal Iconic Styl

Clipsal Iconic Styl

Irresistibly beautiful design made from durable anodised aluminum for a quality look in every home.
