Clipsal Iconic Socket Switch Horizontal Single, 20A, 250V

Clipsal Iconic Socket Switch Horizontal Single, 20A, 250V | Vivid White

Item Number: 3015/20-VW

The Clipsal Iconic Single Power Point is a great option for industrial appliances around the smart home, office or business. With a green indicator strip on the rocker, it’s easy to tell when the switch is on. The slimline finish is customisable with Iconic skins, so you can match or contrast the surrounding decor.

Datasheet

Product Dimensions

Width icon

Width120 mm

Height icon

Height78 mm

Embedding depth icon

Embedding depth24 mm

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range

Clipsal Iconic

Product or component type

switched socket

Colour tint

vivid white (VW)

Physical

Device presentation

complete product

Outlet poles configuration

2P + E

Outlet standard

Australian

Device mounting

flush

Number of power socket outlets

1

Number of rocker

1

Range compatibility

Clipsal Iconic

Outlet standard description

with earthing contact

Ground lug position

straight 180° position

Fixing mode

by screw

Installation direction

horizontal

Type of packing

polybag

Quantity per set

set of 10

Sale per indivisible quantity

1

Rated current

20 A at 250 V AC 50 Hz

Electrical durability

9000 cycles

Connections - terminals

3 screw terminals

Screwdriver shape

<ul><li>Philips No 2</li><li>square drive no 1 (SQ1)</li></ul>

Clamping connection capacity

<ul><li>1 x 2.5...4 x 2.5 mm² for rigid cable(s)</li><li>1 x 2.5...4 x 2.5 mm² for stranded cable(s)</li><li>1 x 2.5...4 x 2.5 mm² for flexible cable(s)</li></ul>

Wire stripping length

16 mm

Height

78 mm

Width

120 mm

Depth

30 mm

Embedding depth

24 mm

Net weight

0.098 kg

Ambient air temperature for operation

0...45 °C

Relative humidity

10...95 %

Standards

AS/NZS 3112

Product certifications

RCM

Reach regulation

Free of Substances of Very High Concern above the threshold

Reach free of svhc

Yes

Eu rohs directive

Compliant

Toxic heavy metal free

Yes

Mercury free

Yes

Rohs exemption information

Yes

China rohs regulation

 Pro-active China RoHS declaration (out of China RoHS legal scope)

Environmental disclosure

ENVPEP1607004EN

Circularity profile

N/A

Material

Material

<ul><li>PC (polycarbonate): fixing frame</li><li>PP (polypropylene): rocker</li><li>PC (polycarbonate): cover frame</li><li>ABS (acrylonitrile butadiene-styrene): cover frame</li></ul>

Others

Package 1 bare product quantity

1

Package 2 bare product quantity

10

Outlet standard deviation

Australian/New Zealand

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

3.7 cm

Package 1 width

7.8 cm

Package 1 length

12 cm

Package 1 weight

83.33 g

Unit type of package 2

BB1

Number of units in package 2

10

Package 2 height

11 cm

Package 2 width

14.8 cm

Package 2 length

33.2 cm

Package 2 weight

1.298 kg

Packaging made with recycled cardboard

Yes

Packaging without single use plastic

No

Sustainable packaging

Yes

Take-back

No

Take-back

No

Product contributes to saved and avoided emissions

No

Removable battery

N/A

Carbon footprint (kg.eq.co2 per cr, total life cycle)

19.72154374
