2000 Series Switched Socket 20A

2000 Series Switched Socket 20A | WE

Item Number: 2010/20-WE

Operate two circuits, as well as plugging in an appliance with the Clipsal 2000 Series Single Switched Outlet with Two Removable Switches. The outlet is rated 10A, 250V and is designed to be installed vertically. The gloss finish and rounded edges make the plate easy to keep clean.

Datasheet

Barcode

Qty UoM EAN Colour
-
-
-

Specifications

Design

Range of product

Series 2000

Product brand

Clipsal

Surface finish

glossy

Sustainable offer status

Green Premium product

Physical

Quantity per set

set of 1

Marking

without marking

Local signalling

without light indicator

Device mounting

flush

Fixing mode

by screws

[in] rated current

20 A

[ue] rated operational voltage

250 V AC

Depth

31 mm

Length

116 mm

Width

76 mm

Fixing center

84 mm

Number of poles

1

Standards

AS/NZS 3100|AS/NZS 3112|AS/NZS 3133:approval number S/1

Reach regulation

Reference contains Substances of Very High Concern above the threshold

Eu rohs directive

Compliant with Exemptions

Mercury free

Yes

China rohs regulation

Product out of China RoHS scope. Substance declaration for your information

Rohs exemption information

Yes

Environmental disclosure

ENVPEP120506EN

Circularity profile

N/A

Material

Material

PVC (polyvinyl chloride)

Others

Package 1 bare product quantity

1

Cover type

full cover plate

Unit type of package 1

PCE

Number of units in package 1

1

Package 1 height

3.1 cm

Package 1 width

7.6 cm

Package 1 length

11.6 cm

Package 1 weight

110 g

Unit type of package 2

BB1

Number of units in package 2

5

Package 2 height

11.9 cm

Package 2 width

8.3 cm

Package 2 length

17.9 cm

Package 2 weight

550 g

Unit type of package 3

CAR

Number of units in package 3

50

Package 3 height

18.2 cm

Package 3 width

30.8 cm

Package 3 length

45.3 cm

Package 3 weight

5.5 kg
Show all specifications
