Specifications
Design
Product brand
Clipsal
Range of product
Electricimagination
Product or component type
splitter block
Physical
Number of terminals
1 earth contact
Connections - terminals
F connection
Transmission frequency
5...2400 MHz
Standards
- Foxtel F10082/C
- Austar A01592
Eu rohs directive
Under investigation
Circularity profile
N/A
Others
Package 1 bare product quantity
1
Maximum splitter loss
11.5 dB
Number of outputs
4
Number of mounting holes
2
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 weight
0.1 kg
